LevelOne Switch 24x GE GTP-2871 4x10GSFP+48,3 cm ( 19 inch ) 400W 24xPoE+
|
642,08 EUR 642,08 EUR |
|
|
( 764,08 EUR incl. VAT ) ≈ £537.42 | ≈ $718.49 plus delivery charges: 55,00 € |
|
| Delivery time from supplier's stock (ca.) 9 workdaysinfo_outline | |
| In Stock: >10 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 1997721 |
| Mfg Part No: | GTP-2871 |
| UPC/EAN: | 4015867228593 |
| Weight: | 4.459 kg |
| Certificates | |
| Compliance certificates | RoHS |
| Certification | CE |
| Data transmission | |
| Switching capacity | 128 Gbit/s |
| Forwarding rate | 95.232 Mpps |
| MAC address table | 16000 entries |
| Maximum data transfer rate | 10 Gbit/s |
| Jumbo frames | 12000 |
| Packet buffer memory | 1.5 MB |
| Store-and-forward | |
| Static route | |
| Jumbo frames support | |
| Design | |
| Product colour | Grey |
| Housing material | Metal |
| Rack mounting | |
| Reset button | |
| LED indicators | |
| Logistics data | |
| Country of origin | China |
| Harmonized System (HS) code | 85176990 |
| Management features | |
| Switch type | Managed |
| Switch layer | L3 |
| Quality of Service (QoS) support | |
| Web-based management | |
| Traffic classification | |
| ARP inspection | |
| Configuring Location Settings (CLI) | |
| System event log | |
| Multicast features | |
| Multicast support | |
| Network | |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3x, IEEE 802.3z |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| 10G support | |
| Port mirroring | |
| Full duplex | |
| Link aggregation | |
| Broadcast storm control | |
| Rate limiting | |
| Spanning tree protocol | |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
| Packaging content | |
| Cables included | AC |
| Quick start guide | |
| Rack mount kit | |
| Packaging data | |
| Package width | 390 mm |
| Package depth | 596 mm |
| Package height | 80 mm |
| Package weight | 6 kg |
| Rubber feet | |
| Resource CD | |
| Performance | |
| Virtual stacking (units) | 4 |
| Internal memory | 512 MB |
| Flash memory | 32 MB |
| Mean time between failures (MTBF) | 150000 h |
| Firmware upgradeable | |
| Plug and Play | |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity | 24 |
| SFP+ module slots quantity | 4 |
| Fiber ports quantity | 4 |
| Fiber optic connector | SFP+ |
| Power connector | AC-in jack |
| Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 6 A |
| Power consumption (typical) | 468.2 W |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) power per port | 30 W |
| Total Power over Ethernet (PoE) budget | 400 W |
| Power over Ethernet (PoE) | |
| Security | |
| DHCP features | DHCP relay, DHCP server, DHCP snooping |
| Authentication | MAC-based authentication |
| Authentication type | RADIUS |
| Queue scheduling algorithms | Priority queuing (PQ), Weighted Round Robin (WRR) |
| Access Control List (ACL) | |
| IGMP snooping | |
| IGMP proxy | |
| Weight & dimensions | |
| Width | 330 mm |
| Depth | 440 mm |
| Height | 44.5 mm |
| Weight | 4.48 kg |
