LevelOne Switch 8x GE GEP-1061 2xGSFP 48,3 cm ( 19 inch ) 180W 8xPoE+
|
259,24 EUR |
|
|
( 308,50 EUR incl. VAT ) ≈ £216.98 | ≈ $290.09 plus delivery charges: 55,00 € |
|
| Delivery time from supplier's stock (ca.) 9 workdaysinfo_outline | |
| In Stock: >100 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 1630231 |
| Mfg Part No: | GEP-1061 |
| UPC/EAN: | 4015867227350 |
| Weight: | 2.047 kg |
| Certificates | |
| Certification | CE class A, FCC, UL, VCCI, BSMI |
| Data transmission | |
| Switching capacity | 20 Gbit/s |
| Forwarding rate | 14.9 Mpps |
| MAC address table | 8000 entries |
| Number of trunks | 8 |
| Number of queues | 8 |
| Jumbo frames | 10000 |
| Packet buffer memory | 4.1 MB |
| Store-and-forward | |
| Static route | |
| Jumbo frames support | |
| Design | |
| Product colour | Black |
| LED indicators | Activity, Link, Power |
| Rack mounting | |
| Stackable | |
| Reset button | |
| Logistics data | |
| Country of origin | China |
| Harmonized System (HS) code | 85176990 |
| Management features | |
| Switch type | Managed |
| Switch layer | L2 |
| Quality of Service (QoS) support | |
| Traffic classification | |
| System event log | |
| Multicast features | |
| Multicast support | |
| Network | |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Virtual LAN features | MAC address-based VLAN, Port-based VLAN, Protocol-based VLAN, Tagged VLAN |
| Number of VLANs | 4000 |
| 10G support | |
| Port mirroring | |
| Flow control support | |
| Link aggregation | |
| Broadcast storm control | |
| Rate limiting | |
| Spanning tree protocol | |
| Cable length detection | |
| VLAN support | |
| Operational conditions | |
| Operating temperature (T-T) | -10 - 50 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 10 - 95% |
| Optical fiber | |
| Fiber ethernet cabling technology | 100BASE-X, 1000BASE-X |
| Packaging content | |
| Cables included | AC, LAN (RJ-45) |
| Quick start guide | |
| Rack mount kit | |
| Packaging data | |
| Package type | Blister |
| Package width | 255 mm |
| Package depth | 82 mm |
| Package height | 345 mm |
| Package weight | 2 kg |
| Resource CD | |
| Performance | |
| Internal memory | 32 MB |
| Noise level | 0 dB |
| Telnet | |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Combo SFP ports quantity | 2 |
| Fiber ports quantity | 2 |
| Fiber optic connector | SFP |
| Console port | RJ-45 |
| Power | |
| Power source | AC |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (typical) | 80 W |
| Power supply included | |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) ports quantity | 8 |
| Power over Ethernet (PoE) power per port | 30 W |
| Total Power over Ethernet (PoE) budget | 125 W |
| Power over Ethernet (PoE) | |
| Protocols | |
| IPv4 & IPv6 features | IPv6 Telnet, IPv6 ping, IPv6 tracert |
| Security | |
| DHCP features | DHCP client, DHCP snooping |
| Access Control List (ACL) rules | 512 |
| Access Control List (ACL) | |
| IGMP snooping | |
| MAC address filtering | |
| SSH/SSL support | |
| BPDU filtering/protection | |
| Password protection | |
| DoS attack prevention | |
| Weight & dimensions | |
| Width | 181 mm |
| Depth | 270 mm |
| Height | 44 mm |
| Weight | 800 g |
Questions & answers
What is the delivery time of LevelOne Switch 8x GE GEP-1061 2xGSFP 48,3 cm ( 19 inch ) 180W 8xPoE+?
The article LevelOne Switch 8x GE GEP-1061 2xGSFP 48,3 cm ( 19 inch ) 180W 8xPoE+ is currently in stock
According to our experience the article is ready for dispatch within 9 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of LevelOne GEP-1061 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you LevelOne Switch 8x GE GEP-1061 2xGSFP 48,3 cm ( 19 inch ) 180W 8xPoE+ always at the best possible price. We can give you a discount of 2% on LevelOne Switch 8x GE GEP-1061 2xGSFP 48,3 cm ( 19 inch ) 180W 8xPoE+ if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
