Lapp 74200600 EPIC SIGNAL M23 BCMS 1 mm AU 0.14–1 (100) flush, gold-plated, slot
|
41,80 EUR 42,57 EUR |
|||||||||||
|
( 49,74 EUR incl. VAT ) ≈ £34.99 | ≈ $45.94 plus delivery charges: 55,00 € |
|||||||||||
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |||||||||||
| Sales unit: 100 pieces | |||||||||||
| Datasheet: | file_download Download | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Lieske Part No.: | 359173 | ||||||||||
| Mfg Part No: | 74200600 | ||||||||||
| UPC/EAN: | 4044773715361 | ||||||||||
| Weight: | 0.123 kg | ||||||||||
| Type: | EPIC M23 BCEMS 1MM AU 0,14-1,0 (100) | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Lapp 74200600:
The item price shown refers to 100 pieces Lapp 74200600
| Certifications | |
| EAC-certified | Not required |
| EAC certification number | Отказное письмо № 39 |
| UR certification | according to UL 2238 (e-file number: E249137) |
| UL category control number | CYJV2 |
| cUR certification | according to CSA C22.2 No. 182.3 (e-file number: E249137) |
| cUR category control number | CYJV8 |
| VDE registration number | C025 |
| Product standard according to IEC | IEC 61984 |
| UR recognised | |
| cUR recognised | |
| VDE certified | |
| Electrical characteristics | |
| Rated current contact | 7 A according to IEC, 7 A according to UL, 7 A according to CSA |
| Max. contact resistance | 4 mΩ |
| General information | |
| Brand | EPIC® |
| Product type | Contact |
| Contact delivery type | Bag |
| Weight | 0 kg |
| Delivery Unit | 100 |
| Installation type | crimp |
| Industry segment | Ships & boats |
| Product characteristics | |
| Contact application areact | Signal |
| Product design | |
| Contact diameter | 1 mm |
| Contact length | 14.2 mm |
| Contact variant | Socket |
| Contact manufacturing method | Machined |
| Conductor connection type | Crimp termination |
| Contact for design | M23, LS1 |
| Stripping length of single core | 6.5 mm |
| Min. connectable conductor cross-section AWG | 26 AWG |
| Max. connectable conductor cross-section AWG | 18 AWG |
| Min. connectable conductor cross-section (mm2) | 0.14 mm² |
| Max. connectable conductor cross-section (mm2) | 1 mm² |
| Contact material | Brass |
| Contact material, short form | CuZn |
| Contact coating material | Gold-plated |
| Contact coating material, short form | Au |
| Colour | gold |
Questions & answers
What is the delivery time of Lapp 74200600 EPIC SIGNAL M23 BCMS 1 mm AU 0.14–1 (100) flush, gold-plated, slot ?
The article Lapp 74200600 EPIC SIGNAL M23 BCMS 1 mm AU 0.14–1 (100) flush, gold-plated, slot is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Lapp 74200600 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Lapp 74200600 EPIC SIGNAL M23 BCMS 1 mm AU 0.14–1 (100) flush, gold-plated, slot always at the best possible price. We can give you a discount of 2% on Lapp 74200600 EPIC SIGNAL M23 BCMS 1 mm AU 0.14–1 (100) flush, gold-plated, slot if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduated prizes with every purchase. If you buy a minimum of 10 pieces of Lapp 74200600 EPIC SIGNAL M23 BCMS 1 mm AU 0.14–1 (100) flush, gold-plated, slot we can offer you a price of 41,17 EUR per piece. The more you buy, the cheaper the article will be.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
How many units does the article contain?
Lapp 74200600 EPIC SIGNAL M23 BCMS 1 mm AU 0.14–1 (100) flush, gold-plated, slot is offered by us in a sales unit of 100 pieces If you need a larger quantity, you can contact us at any time. We will make a special offer for you
