Lapp 74034101 EPIC POWER LS1 F SCEM 2mm AU 0.5-2.5 (10) pin gold-plated crimp
|
23,94 EUR 24,16 EUR |
|||||||||||
|
( 28,49 EUR incl. VAT ) ≈ £20.04 | ≈ $26.31 plus delivery charges: 55,00 € |
|||||||||||
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |||||||||||
| Sales unit: 10 pieces | |||||||||||
| Datasheet: | file_download Download | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Lieske Part No.: | 461168 | ||||||||||
| Mfg Part No: | 74034101 | ||||||||||
| UPC/EAN: | 4044773535914 | ||||||||||
| Weight: | 0.123 kg | ||||||||||
| Type: | LS1 F SCEM 2MM AU 0,5-2,5 (10) | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Lapp 74034101:
The item price shown refers to 10 pieces Lapp 74034101
| Certifications | |
| EAC-certified | Not required |
| EAC certification number | Отказное письмо № 39 |
| UR certification | according to UL 2238 (CCN: CYJV2 / e-file number: E249137) |
| UL category control number | CYJV2 |
| cUR certification | according to CSA C22.2 No. 182.3 (CCN: CYJV8 / e-file number: E249137) |
| cUR category control number | CYJV8 |
| VDE registration number | B025 |
| Product standard according to IEC | IEC 61984, IEC 60352-2 |
| UR recognised | |
| cUR recognised | |
| VDE certified | |
| Electrical characteristics | |
| Rated current contact | 22 A according to IEC, 22 A according to UL, 22 A according to CSA |
| Max. contact resistance | 4 mΩ |
| General information | |
| Brand | EPIC® |
| Product type | Contact |
| Contact delivery type | Bag |
| Weight | 0.002 kg |
| Delivery Unit | 10 |
| Installation type | crimp |
| Product characteristics | |
| Contact application areact | Energy |
| Product design | |
| Contact diameter | 2 mm |
| Contact variant | Pin |
| Contact manufacturing method | Machined |
| Conductor connection type | Crimp termination |
| Contact for design | LS1 |
| Stripping length of single core | 8 mm |
| Min. connectable conductor cross-section AWG | 20 AWG |
| Max. connectable conductor cross-section AWG | 14 AWG |
| Min. connectable conductor cross-section (mm2) | 0.5 mm² |
| Max. connectable conductor cross-section (mm2) | 2.5 mm² |
| Contact material | Brass |
| Contact material, short form | CuZn |
| Contact coating material | Gold-plated |
| Contact coating material, short form | Au |
| Colour | gold |
Questions & answers
What is the delivery time of Lapp 74034101 EPIC POWER LS1 F SCEM 2mm AU 0.5-2.5 (10) pin gold-plated crimp ?
The article Lapp 74034101 EPIC POWER LS1 F SCEM 2mm AU 0.5-2.5 (10) pin gold-plated crimp is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Lapp 74034101 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Lapp 74034101 EPIC POWER LS1 F SCEM 2mm AU 0.5-2.5 (10) pin gold-plated crimp always at the best possible price. We can give you a discount of 2% on Lapp 74034101 EPIC POWER LS1 F SCEM 2mm AU 0.5-2.5 (10) pin gold-plated crimp if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduated prizes with every purchase. If you buy a minimum of 15 pieces of Lapp 74034101 EPIC POWER LS1 F SCEM 2mm AU 0.5-2.5 (10) pin gold-plated crimp we can offer you a price of 22,86 EUR per piece. The more you buy, the cheaper the article will be.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
How many units does the article contain?
Lapp 74034101 EPIC POWER LS1 F SCEM 2mm AU 0.5-2.5 (10) pin gold-plated crimp is offered by us in a sales unit of 10 pieces If you need a larger quantity, you can contact us at any time. We will make a special offer for you
