Lapp multiple sealing insert M25 3x5mm, Skintop-DIX-M25350 content_copy

Multiple sealing insert SKINTOP® DIX-M 25350, Multiple sealing insert, M 25, Number of cable entries: 3, Bore diameter: 5mm, black, Areas of application: Suitable for outdoor use, For use with metric SKINTOP® / SKINTOP® CLICK cable glands, Benefits: Gentle clamping of the cables due to the high elasticity of the sealing insert material, Easy insertion of several cables through a cable gland, Protection class IP 68 can be achieved provided that all holes are occupied by cables with a nominal diameter and unused openings are closed with SKINTOP® DIX-DV sealing closures, Multiple cable entries enable a higher packing density, Wide range of variants available, depending on the number and diameter of cables Made of acrylonitrile butadiene rubber (NBR), fluororubber (FKM) or silicone (SI)
, The FKM variants are resistant to aggressive media such as alkalis, acids, solvents and are also oil-resistant They are extremely heat-resistant and suitable for use at extreme temperatures (up to +200 °C). The silicone variants are resistant to ECOLAB® cleaning and disinfection agents and are chemically resistant in many ways. They comply with FDA 21 CFR 1772600 and are therefore approved for the food and beverage industry. Their blue color makes them easy to distinguish from food. They are also extremely flexible at low temperatures and suitable for use at extreme temperatures (down to -50 °C). The NBR variants are oil-resistant.
Type: SKINTOP/DIX-M/25350
