Lapp 2210704 H01N2-D 1x 70 normative arc welding cable
|
15,30 EUR |
|||||||||||
|
incl. 7,55 EUR copper surcharge ( 18,21 EUR incl. VAT ) ≈ £12.74 | ≈ $16.78 plus delivery charges: 55,00 € |
|||||||||||
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |||||||||||
| Lieske Part No.: | 458324 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 2210704 | ||||||||||
| UPC/EAN: | 4044773099072 | ||||||||||
| Weight: | 1.082 kg | ||||||||||
| Type: | H01N2-D 1X70 SCHWEIßLEITUNG | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Lapp 2210704:
Applications
The cable is suitable for flexible use in dry, damp, rough, and oily environments. It can be used temporarily outdoors, making it suitable for construction sites or temporary outdoor workspaces. The operating temperature ranges down to -25 °C, making it suitable for colder working conditions as well. The cable is intended for free use in air, without tensile stress, and withstands high mechanical loads.
Functions and Equipment in Detail
The cable features a flexible design that enables safe transmission of high currents. The rubber hose cable is insulated with rubber material, offering high mechanical strength and resistance to oil and moisture. The construction ensures reliable current transmission under heavy loads, which is crucial for welding technology. The cable is configured as 1X70, meaning it consists of a single conductor with a cross-section of 70 mm².
Technology Explained Simply
The designation H01N2-D describes the harmonized European type defined for welding cables. The voltage class U0/U: 100/100 V means the cable is designed for an operating voltage of up to 100 V between conductor and earth, as well as between conductors. The HAR certification is a quality and safety assurance that confirms compliance with European standards. The cable is flexible and can be used at temperatures down to -25 °C, making it suitable for industrial applications in various climatic conditions.
Compatibility and Accessories
The cable is specifically designed for connecting arc welding machines to hand-held electrode holders. It is compatible with standard welding machines operating at a nominal voltage up to 100 V. No additional adapters or special connection components are required, as the cable connects directly to the machines.
Installation and Mounting
Mounting is done without tensile stress, freely in air. The cable is designed for flexible use, making it well-suited for work areas with frequent movements. Installation does not require special tools or accessories, as the cable connects directly to the welding machines.
Operational Advantages
The rubber hose cable offers high mechanical strength and resistance to oil and moisture. The flexible construction enables safe current transmission under heavy loads, which is essential for welding technology. The HAR certification ensures compliance with European standards and acceptance in various countries. The cable is suitable for use in harsh environments and withstands high mechanical loads.
| General | |
| Construction | H01N2-D - |
| Test mark | HAR - |
| Nominal voltage | 100 V |
| Voltage class | 100/100 V |
| Conductor cross section | 70 mm² |
| Number of conductors | 1 - |
| Insulating material | Rubber - |
| Working temperature | -25 °C |
| Application range | Free in air, without tension - |
| Application | arc welding machine and hand-held electrode holder - |
| Approval | harmonised European design - |
The final cable weight will be determined before invoicing. The calculation is based on the copper content and any additional weight due to drums, pallets, or outer packaging. Prices are subject to this subsequent calculation.
Please note that for cables, that are not in stock and must be produced, the manufacturer may need an order of a minimum length that can be 5-10km depending on cable type!
