Lapp 2210701 H01N2-D 1x 25 normative arc welding cable

Your rating:
Average rating
product review for Lapp 2210701 H01N2-D 1x 25 normative arc welding cable
( 4.6 / 5 ) 19 ratings
Lapp 2210701
This image may differ from the desired article.
Lapp 2210701Lapp 2210701
5,97 EUR
incl. 2,70 EUR copper surcharge
( 7,10 EUR incl. VAT )
≈ £4.97  |  ≈ $6.55
plus delivery charges: 55,00 €
Made to order · Delivery time approx. 20 workdaysinfo_outline
1x Lapp 2210701 H01N2-D 1x 25 normative arc welding cable
Lieske Part No.:1325032
Mfg Part No: 2210701
UPC/EAN: 4044773099195
Weight:0.305 kg
Type:H01N2-D 1X25
Graduated prices net
From piecesPrice per meters
505,72 EUR
1005,48 EUR
2505,23 EUR
5004,99 EUR

Product information for Lapp 2210701:

The H01N2-D 1X25 connection cable from Lapp is a rubber hose cable, specifically designed for use in arc welding technology. It is used to connect an arc welding machine to a hand-held electrode holder and is rated for nominal voltages up to 100 V. The cable is manufactured according to the harmonized European type H01N2-D and carries the ¿HAR¿ test mark, which stands for tested safety and quality. This certification ensures that the cable complies with European standards and is widely accepted throughout the EU.

Applications

The cable is suitable for flexible use in dry, damp, as well as rough and oily environments. It can be used temporarily outdoors, making it suitable for construction sites or industrial outdoor installations. The operating temperature ranges down to -25 °C, enabling use in colder environments. The cable is intended for free use in air, without tensile stress, and withstands high mechanical loads.

Functions and Equipment in Detail

The connection cable features a flexible design that enables secure transmission of high currents. The conductor cross-section is 25 mm², which is sufficient for the required current transmission in welding applications. The insulation is made of rubber, providing high mechanical strength and resistance to oil and moisture. The cable is flexible and therefore suitable for moving applications requiring high mobility and load capacity.

Technology Explained Simply

The designation H01N2-D describes a harmonized European cable type specifically developed for welding applications. The marking 1X25 indicates that it is a single-conductor cable with a conductor cross-section of 25 mm². The voltage rating U0/U: 100/100 V indicates that the cable is designed for an operating voltage of 100 V between conductor and earth as well as between conductors. The ¿HAR¿ test mark guarantees that the cable meets European safety and quality requirements.

Compatibility and Accessories

The cable is specifically designed for connecting arc welding machines to hand-held electrode holders. It is compatible with standard connection plugs and sockets commonly used in welding technology. No additional adapters or special accessories are required, as the cable can be directly connected to welding machines.

Installation and Mounting

Installation is carried out without tensile stress, freely in air. The cable is not intended for installation in pipes or ducts, but for open use. Mounting does not require special tools, as the cable is directly connected to welding machines. The connection is made using standard connection plugs commonly used in welding technology.

Advantages in Operation

The cable offers high mechanical strength and resistance to oil and moisture, making it suitable for harsh industrial environments. The flexible construction allows for easy handling and movement during the welding process. The ¿HAR¿ certification ensures safe and reliable current transmission, increasing operational safety. The operating temperature down to -25 °C extends the range of applications to colder regions or outdoor welding work.

General
Cable typeH01N2-D -
Conductor cross section25 mm²
Nominal voltage100 V
Voltage markingU0/U: 100/100 V -
Insulating materialRubber -
FlexibilityFlexible -
ApprovalHAR-certified -
Working temperature-25 °C
Installation methodFree in air, without tension -


Please note...
For this article, we charge 14,85 EUR for measuring, cutting and re-furling the cable. If you take a whole 100m or 500m cable reel, the charge will of course be dropped.

The final cable weight will be determined before invoicing. The calculation is based on the copper content and any additional weight due to drums, pallets, or outer packaging. Prices are subject to this subsequent calculation.

Please note that for cables, that are not in stock and must be produced, the manufacturer may need an order of a minimum length that can be 5-10km depending on cable type!
This article contains a copper surcharge of 2,70 EUR. This depends on daily copper prices and weight of included copper. You can inquire the copper price via phone under +49 7666 884990

Questions & answers

What is the delivery time of Lapp 2210701 H01N2-D 1x 25 normative arc welding cable ?

The article Lapp 2210701 H01N2-D 1x 25 normative arc welding cable is currently not in stock and must be ordered on a per-order basis.

According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Lapp 2210701 to our sales team for an exact delivery time.

How can I buy the item at a lower price?

We offer you Lapp 2210701 H01N2-D 1x 25 normative arc welding cable always at the best possible price. We can give you a discount of 2% on Lapp 2210701 H01N2-D 1x 25 normative arc welding cable if you choose payment in advance on ordering.

In addition, you can save money with our attractive graduated prizes with every purchase. If you buy a minimum of 50 meters of Lapp 2210701 H01N2-D 1x 25 normative arc welding cable we can offer you a price of 5,72 EUR per piece. The more you buy, the cheaper the article will be.
