Lapp 21700541 ED-PB-90-RP-PG PROFIBUS Sub-D plug 90° screw connection with LEDs

Your rating:
Average rating
product review for Lapp 21700541 ED-PB-90-RP-PG PROFIBUS Sub-D plug 90° screw connection with LEDs
( 4.4 / 5 ) 27 ratings
Lapp 21700541
This image may differ from the desired article.
Lapp 21700541Lapp 21700541
355,36 EUR 357,80 EUR
( 422,88 EUR incl. VAT )
≈ £297.44  |  ≈ $390.54
plus delivery charges: 55,00 €
Made to order · Delivery time approx. 20 workdaysinfo_outline
1x Lapp 21700541 ED-PB-90-RP-PG PROFIBUS Sub-D plug 90° screw connection with LEDs
Datasheet:file_download Download
Lieske Part No.:461824
Mfg Part No: 21700541
UPC/EAN: 4044774758947
Weight:0.04 kg
Type:ED-PB-90-RP-PG
Graduated prices net
From piecesPrice per pieces
4352,69 EUR
8350,03 EUR
12347,36 EUR
16344,70 EUR

Product information for Lapp 21700541:

The ED-PB-90-RP-PG data connector from Lapp is a PROFIBUS DP-compatible connector in Sub-D form, specifically designed for use in industrial automation networks. It features a right-angled (90°) cable exit and is equipped with a screw connection for connecting PROFIBUS-compliant cables. The design enables compact mounting, particularly in installations with limited space. The connector is configured as a Repeater, thereby regenerating the received data signal and enabling extension of the PROFIBUS network over longer distances. Additionally, it includes a diagnostic interface, supporting separate programming and diagnostic functions via a second D-Sub interface (variant 'PG'). Status indication is provided by colored LEDs, visually signaling the operating state.

Applications
This connector is intended for integration into PROFIBUS®-DP networks. It is suitable for connecting PROFIBUS-compliant cables with an outer diameter of 5 to 8 mm. Alternatively, it can be pre-assembled with a PROFIBUS®-M12 connector (B-coded) for use. Applications are in industrial environments where reliable and interference-free data transmission is required, such as in manufacturing automation, process engineering, or machine building.

Functions and Equipment in Detail
A central feature is the integrated, switchable termination resistor function via a sliding switch. This allows the connector to be flexibly used as a pass-through or terminating connector, depending on the network topology requirements. The status indication via colored LEDs enables quick visual inspection of the operating state, making maintenance and diagnostic work more efficient. The 'PG' variant offers an additional D-Sub interface for programming and diagnostics.

Technology Explained Simply
The connector uses Sub-D connector technology, a widely used interface in industrial automation. The right-angled design (90°) reduces mechanical stress on cables and facilitates installation in confined spaces. The screw connection ensures a secure and durable connection. The integrated repeater function regenerates the received signal, maintaining signal quality over longer distances. The metallized housing provides enhanced protection against electromagnetic interference, increasing the reliability of data transmission. UL certification enables use of the product in the North American market.

Compatibility and Accessories
The connector is designed for use with PROFIBUS®-DP-compliant cables. It can be connected to cables with an outer diameter of 5 to 8 mm. Alternatively, pre-assembly with a PROFIBUS®-M12 connector (B-coded) is possible. The design is available in various cable exit angles (35°, 90°, 180°), ensuring application-specific mounting. Compatibility with other PROFIBUS-compatible devices is standard-compliant.

Mounting and Installation
Mounting is done via the integrated screw connection, ensuring a secure and mechanically stable connection. The right-angled design (90°) facilitates placement in tight mounting areas. The sliding switches for activating termination resistors are directly accessible on the device, allowing easy on-site configuration. Installation requires no additional tools, with connection security ensured by the screw connection.

Operational Advantages
The connector offers high operational reliability through the integrated repeater function and termination resistor function. Visual status indication via LEDs reduces fault diagnosis time. The compact design and right-angled configuration enable flexible mounting in space-limited environments. UL certification expands the application scope to the North American market. The metallized housing construction provides enhanced protection against electromagnetic interference, improving signal integrity in industrial operation.

General
InterfacePROFIBUS DP
Plug typeSub-D
Cable exit angle90°
Connection systemScrew connection
FunctionRepeater
Status indicatorLEDs
Terminal resistorswitchable via slide control
HousingMetallized
ApprovalUL
CompatibilityPROFIBUS-compliant cables (5–8 mm) or M12 connectors (B-coded)
Construction typeangled
Diagnostics interfaceYes
Certifications
EAC-certifiedNot required
EAC certification numberОтказное письмо № 39
CE markingyes
UL recognizedno
UL listedno
cUR recognisedno
cUL listedno
CSA certifiedno
Electrical characteristics
Impedance150 Ω
General information
BrandEPIC®
Product typeData connector
Weight0.04 kg
Delivery Unit1
valid fieldbus or Ethernet systemPROFIBUS DP
Product characteristics
Variant of the Sub-DRepeater, With diagnostic interface
IP protection ratingIP 20
Pollution degree2
Operating temperature min.0 °C
Operating temperature max.60 °C
For use in hazardous areasno
UV-resistantno
Fast Connect (FC) cableno
Product design
Total length64 mm
Overall width40 mm
Overall height17 mm
Connector housing designAngled
Connector formatSub-D
Connector typePlug/socket
Connector housing angle90 °
For min. cable outer diameter5 mm
For max. cable outer diameter8 mm
Assembly typeField configurable
Conductor connection typeScrew connection
Shieldedno
Status displayyes
Codedno
With threadno
Reusableyes
Diagnostic interfaceyes


Product data sheet
Datasheet for Lapp 21700541, EAN: 4044774758947
