Klauke HR495 crimping die HK4er 95 mm² for pipe cable lugs/connectors 6-sided

Your rating:
Average rating
product review for Klauke HR495 crimping die HK4er 95 mm² for pipe cable lugs/connectors 6-sided
( 4.4 / 5 ) 24 ratings
Klauke HR495
This image may differ from the desired article.
Klauke HR495Klauke HR495
140,65 EUR 142,05 EUR
( 167,37 EUR incl. VAT )
≈ £117.72  |  ≈ $154.57
plus delivery charges: 55,00 €
Made to order · Delivery time approx. 20 workdaysinfo_outline
1x Klauke HR495 crimping die HK4er 95 mm² for pipe cable lugs/connectors 6-sided
Lieske Part No.:343403
Mfg Part No: HR495
UPC/EAN: 4012078035194
Weight:0.071 kg
Type:HR495
Graduated prices net
From piecesPrice per pieces
5139,60 EUR
10138,54 EUR
15137,49 EUR
20136,43 EUR

Product information for Klauke HR495:

The HR495 crimping die from Klauke is a tool accessory for processing pipe cable lugs and connectors made of copper (Cu) in standard configuration. It belongs to Series 4 and is specifically designed for cross-sections of 95 mm². The die is used for secure and precise crimping of cable lugs, particularly for switchgear connections, where a stable and durable electrical connection is required. It is used in electrical installation and industrial applications where high mechanical loads and electrical conductivity are required.

Applications

The HR495 crimping die is designed for use with pipe cable lugs and connectors installed in switchgear, such as power switches, fuses, or connection boxes. Crimping is performed using a suitable crimping tool, where the die adapts the tool's shape to the geometry of the cable lug. The die is used in electrical installation, during the assembly of distributors, in industrial electrical engineering, as well as in the maintenance and repair of electrical systems. The standard configuration ensures standardized processing that meets the requirements of qualified electricians.

Functions and Features in Detail

The crimping die is designed for a cable cross-section of 95 mm², making it suitable for medium to large cables in industrial and commercial applications. It is intended for pipe cable lugs and connectors made of copper (Cu), which offer high electrical conductivity and mechanical strength. The shape of the die is adapted to the hexagonal geometry of the cable lugs to be crimped, ensuring uniform and complete deformation. Crimping is performed by mechanical force transmission through the crimping tool, securing the cable lug firmly and permanently to the conductor.

Technology Explained Simply

The HR495 die is part of a tool system consisting of a crimping tool and matching dies. The crimping tool transmits the required force to the die, which replicates the shape of the cable lug. During crimping, the cable lug is plastically deformed by the die's shape, allowing it to securely grip the conductor. The hexagonal shape ensures even force distribution and prevents uneven deformation. The standard configuration means the die complies with common standards for cable lug crimping, enabling a safe and reproducible connection.

Compatibility and Accessories

The HR495 crimping die is designed for tools from Klauke's Series 4. It is specifically intended for processing pipe cable lugs and connectors with a cross-section of 95 mm². Compatibility is limited to Series 4 tools, with precise fit ensured by the hexagonal geometry.

Installation and Mounting

Installation involves inserting the crimping die into the corresponding Series 4 crimping tool. The tool is positioned over the cable lug, and crimping is performed by actuating the tool. Crimping is carried out under controlled force to ensure uniform and complete deformation of the cable lug. The process requires no additional tools or accessories.

Operational Advantages

The HR495 die enables precise and reproducible crimping of cable lugs, increasing the reliability of the electrical connection. The standard configuration ensures compatibility with common cable lugs and connectors. The hexagonal shape ensures even force distribution, reducing the risk of cracks or incomplete crimping. Use with Klauke's Series 4 tools ensures high precision and tool stability, increasing work efficiency.

General
Series4
Cable cross-section95 mm²
MaterialCu
ApplicationPipe cable lug and connectors
ModelStandard version


Questions & answers

What is the delivery time of Klauke HR495 crimping die HK4er 95 mm² for pipe cable lugs/connectors 6-sided?

The article Klauke HR495 crimping die HK4er 95 mm² for pipe cable lugs/connectors 6-sided is currently not in stock and must be ordered on a per-order basis.

According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Klauke HR495 to our sales team for an exact delivery time.

How can I buy the item at a lower price?

We offer you Klauke HR495 crimping die HK4er 95 mm² for pipe cable lugs/connectors 6-sided always at the best possible price. We can give you a discount of 2% on Klauke HR495 crimping die HK4er 95 mm² for pipe cable lugs/connectors 6-sided if you choose payment in advance on ordering.

In addition, you can save money with our attractive graduated prizes with every purchase. If you buy a minimum of 5 pieces of Klauke HR495 crimping die HK4er 95 mm² for pipe cable lugs/connectors 6-sided we can offer you a price of 139,60 EUR per piece. The more you buy, the cheaper the article will be.

We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
