Klauke 47212 wire end ferrule insulated 1.5 mm² 12 mm black DIN 46228-4 Cu galvanically zinc-plated
|
5,48 EUR 5,71 EUR |
|||||||||||
|
( 6,52 EUR incl. VAT ) ≈ £4.58 | ≈ $6.10 plus delivery charges: 55,00 € |
|||||||||||
| Delivery time from supplier's stock (ca.) 3 workdaysinfo_outline | |||||||||||
| Sales unit: 100 pieces | |||||||||||
| In Stock: >100 pieces | |||||||||||
| Lieske Part No.: | 744779 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 47212 | ||||||||||
| UPC/EAN: | 4012078023740 | ||||||||||
| Weight: | 0.0157 kg | ||||||||||
| Type: | 47212 | ||||||||||
|
Graduated prices net
|
|||||||||||
Further Sleeves, blank - isolated from KlaukeFurther products in category Sleeves, blank - isolated
All products of Klauke
Product information for Klauke 47212:
The wire end ferrule 47212 from Klauke is an insulated end ferrule for fine- and extra-fine stranded conductors, particularly for cables according to DIN EN 60228 class 5 and 6. It is designed for secure and durable cable connections to screw terminals or other connection points in the field of electrical installation technology. The end ferrule features Easy-Entry insulation, enabling splice-free cable entry and thus reducing installation time. The insulation is halogen-free, making it suitable for applications where the avoidance of toxic fumes in case of fire is required.
Wire end ferrule
The wire end ferrule 47212 is specifically designed for cable cross-sections of 1.50 mm². The total length is 18 mm, with the insulated length being 12 mm. The colour is black, corresponding to the colour coding according to DIN 46228 part 4. This standard defines the dimensions and colours for wire end ferrules to ensure uniform and safe use in electrical installations. The end ferrule is designed for use in electrical systems where high reliability and mechanical stability are required.
Functions and equipment in detail
The Easy-Entry insulation allows for quick and clean cable insertion into the end ferrule without additional processing or splicing. This reduces installation time and minimizes the risk of cable damage. The insulation is made of PVC and offers temperature resistance up to 105 °C, making it suitable for use in environments with increased thermal loads. The end ferrule is halogen-free, meaning no toxic fumes are released in case of fire, which is particularly important in enclosed spaces or buildings with high visitor traffic.
Technology explained simply
The wire end ferrule consists of a metallic core surrounded by PVC insulation. The metallic core is galvanized zinc-plated, ensuring high corrosion resistance and long service life. The insulation protects the cable cross-section from mechanical damage and electrical short circuits. The total length of 18 mm and insulated length of 12 mm allow for a secure connection to screw terminals without damaging the insulation. The temperature resistance up to 105 °C ensures the end ferrule remains stable even at elevated operating temperatures.
Compatibility and accessories
The wire end ferrule 47212 is suitable for cables according to DIN EN 60228 class 5 and 6, which includes fine- and extra-fine stranded conductors. It is compatible with DIN 46228 part 4, which defines the dimensions and colour coding for wire end ferrules. Suitable accessories available in the range include wire end ferrules with identical specifications (1.50 mm², 12 mm, black), also suitable for fine- and extra-fine stranded conductors. The end ferrule is CSA-listed, confirming its approval for use in Canada and certain regions of the USA.
Installation and mounting
Installation is performed by simply inserting the cable into the end ferrule, where the Easy-Entry insulation enables a clean and quick connection. The end ferrule is then placed into a screw terminal and tightened. The galvanized zinc plating of the metallic core ensures high mechanical strength and corrosion resistance. The insulation protects the cable cross-section and prevents short circuits. Installation requires no additional tools or materials, as the end ferrule is directly slipped onto the cable.
Advantages in operation
The wire end ferrule 47212 provides a reliable and durable connection that remains stable even under high mechanical and thermal loads. The halogen-free insulation increases safety in case of fire, while the Easy-Entry insulation reduces installation time. Compliance with DIN 46228 part 4 and CSA listing ensures suitability for various applications, including industrial and commercial electrical installations. The galvanized zinc plating of the metallic core ensures long service life and high corrosion resistance.
The product is delivered in packs of 1000 pieces, making it suitable for large projects and series installations. The end ferrules are packaged in a stable container to prevent transport damage. The packaging is designed to allow easy removal and installation of the end ferrules without causing damage.
The item price shown refers to 100 pieces Klauke 47212
Wire end ferrule
The wire end ferrule 47212 is specifically designed for cable cross-sections of 1.50 mm². The total length is 18 mm, with the insulated length being 12 mm. The colour is black, corresponding to the colour coding according to DIN 46228 part 4. This standard defines the dimensions and colours for wire end ferrules to ensure uniform and safe use in electrical installations. The end ferrule is designed for use in electrical systems where high reliability and mechanical stability are required.
Functions and equipment in detail
The Easy-Entry insulation allows for quick and clean cable insertion into the end ferrule without additional processing or splicing. This reduces installation time and minimizes the risk of cable damage. The insulation is made of PVC and offers temperature resistance up to 105 °C, making it suitable for use in environments with increased thermal loads. The end ferrule is halogen-free, meaning no toxic fumes are released in case of fire, which is particularly important in enclosed spaces or buildings with high visitor traffic.
Technology explained simply
The wire end ferrule consists of a metallic core surrounded by PVC insulation. The metallic core is galvanized zinc-plated, ensuring high corrosion resistance and long service life. The insulation protects the cable cross-section from mechanical damage and electrical short circuits. The total length of 18 mm and insulated length of 12 mm allow for a secure connection to screw terminals without damaging the insulation. The temperature resistance up to 105 °C ensures the end ferrule remains stable even at elevated operating temperatures.
Compatibility and accessories
The wire end ferrule 47212 is suitable for cables according to DIN EN 60228 class 5 and 6, which includes fine- and extra-fine stranded conductors. It is compatible with DIN 46228 part 4, which defines the dimensions and colour coding for wire end ferrules. Suitable accessories available in the range include wire end ferrules with identical specifications (1.50 mm², 12 mm, black), also suitable for fine- and extra-fine stranded conductors. The end ferrule is CSA-listed, confirming its approval for use in Canada and certain regions of the USA.
Installation and mounting
Installation is performed by simply inserting the cable into the end ferrule, where the Easy-Entry insulation enables a clean and quick connection. The end ferrule is then placed into a screw terminal and tightened. The galvanized zinc plating of the metallic core ensures high mechanical strength and corrosion resistance. The insulation protects the cable cross-section and prevents short circuits. Installation requires no additional tools or materials, as the end ferrule is directly slipped onto the cable.
Advantages in operation
The wire end ferrule 47212 provides a reliable and durable connection that remains stable even under high mechanical and thermal loads. The halogen-free insulation increases safety in case of fire, while the Easy-Entry insulation reduces installation time. Compliance with DIN 46228 part 4 and CSA listing ensures suitability for various applications, including industrial and commercial electrical installations. The galvanized zinc plating of the metallic core ensures long service life and high corrosion resistance.
The product is delivered in packs of 1000 pieces, making it suitable for large projects and series installations. The end ferrules are packaged in a stable container to prevent transport damage. The packaging is designed to allow easy removal and installation of the end ferrules without causing damage.
The item price shown refers to 100 pieces Klauke 47212
| General | |
| Cable cross-section | 1,50 mm² |
| Insulated length | 12 mm |
| Total length | 18 mm |
| Colour | Black |
| Temperature resistance | up to 105 °C |
| Insulating material | PVC |
| Norm | DIN 46228 Part 4 |
| Approval | CSA listed |
| Number per pack | 1000 piece |
| Cable class | 5 and 6 |
| Halogen free | |
Questions & answers
What is the delivery time of Klauke 47212 wire end ferrule insulated 1.5 mm² 12 mm black DIN 46228-4 Cu galvanically zinc-plated?
The article Klauke 47212 wire end ferrule insulated 1.5 mm² 12 mm black DIN 46228-4 Cu galvanically zinc-plated is currently in stock
According to our experience the article is ready for dispatch within 3 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Klauke 47212 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Klauke 47212 wire end ferrule insulated 1.5 mm² 12 mm black DIN 46228-4 Cu galvanically zinc-plated always at the best possible price. We can give you a discount of 2% on Klauke 47212 wire end ferrule insulated 1.5 mm² 12 mm black DIN 46228-4 Cu galvanically zinc-plated if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduated prizes with every purchase. If you buy a minimum of 25 pieces of Klauke 47212 wire end ferrule insulated 1.5 mm² 12 mm black DIN 46228-4 Cu galvanically zinc-plated we can offer you a price of 5,07 EUR per piece. The more you buy, the cheaper the article will be.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
How many units does the article contain?
Klauke 47212 wire end ferrule insulated 1.5 mm² 12 mm black DIN 46228-4 Cu galvanically zinc-plated is offered by us in a sales unit of 100 pieces If you need a larger quantity, you can contact us at any time. We will make a special offer for you
