Klauke 12SG12 pipe cable lug 240 mm² M12 for switching devices

Your rating:
Average rating
product review for Klauke 12SG12 pipe cable lug 240 mm² M12 for switching devices
( 4.5 / 5 ) 44 ratings
Klauke 12SG12
This image may differ from the desired article.
Klauke 12SG12Klauke 12SG12Klauke 12SG12Klauke 12SG12
14,12 EUR
incl. 1,93 EUR copper surcharge
( 16,80 EUR incl. VAT )
≈ £11.82  |  ≈ $15.52
plus delivery charges: 55,00 €
Delivery time from supplier's stock (ca.) 3 workdaysinfo_outline
In Stock: >25 pieces
1x Klauke 12SG12 pipe cable lug 240 mm² M12 for switching devices
Lieske Part No.:555346
Mfg Part No: 12SG12
UPC/EAN: 4012078460996
Weight:0.1468 kg
Type:12SG12
Graduated prices net
From piecesPrice per pieces
1513,48 EUR
3012,84 EUR
7012,20 EUR
10011,56 EUR

Product information for Klauke 12SG12:

The cable lug 12SG12 from Klauke is a tube cable lug for use in switchgear, particularly in devices with limited connection space. It is specifically designed for multi-strand conductors, for example according to VDE 0295 Class 2, and is also suitable for round-pressed multi-strand sector conductors. The slim design enables optimal space utilisation in compact switchgear and is achieved through a modern manufacturing process without material loss. The cable lug is made from annealed copper material specified according to EN 13600, ensuring high crimpability and material stability. The surface is galvanically tinned to prevent corrosion and ensure long-term electrical conductivity.

Tube cable lug
The 12SG12 is a tube cable lug featuring a cylindrical shape designed for connection to screw terminals in switchgear. The special forming technique ensures a flat contact surface, guaranteeing a secure and even contact. The ends of the cable lug are precisely machined to facilitate cable insertion and enable clean processing. This design reduces the risk of cable damage during installation and ensures a reliable electrical connection.

Applications
The cable lug is primarily intended for use in switchgear, especially in devices where the available connection space is limited. It is commonly used in industrial electrical installations, distribution boxes, or enclosures where a compact and secure connection is required. Its suitability for multi-strand conductors, as defined in VDE 0295 Class 2, makes it particularly appropriate for applications involving flexible cables requiring high mobility.

Functions and equipment in detail
The use of annealed copper material according to EN 13600 ensures optimal crimpability, guaranteeing a firm and durable connection between cable and screw terminal. The galvanic tinning protects the surface from oxidation and corrosion, extending the service life of the cable lug and maintaining stable electrical conductivity over time. The special forming technique provides a flat contact surface, enabling even distribution of screw force and thus ensuring a secure contact.

Technology explained simply
The cable lug is screwed into the switchgear using a screw, with the cable inserted into the cylindrical part of the lug. Crimping is achieved by the screw force, which secures the cable inside the lug. The use of annealed copper ensures the material is elastic enough to securely grip the cable without damaging it. The galvanic tinning prevents oxide formation on the surface, which could impair electrical conductivity.

Compatibility and accessories
The cable lug is designed for multi-strand conductors, particularly those according to VDE 0295 Class 2, and is also suitable for round-pressed multi-strand sector conductors. It is designed for use in switchgear with reduced connection space, making it ideal for compact devices and enclosures. The special shape and precise end machining facilitate installation and ensure clean processing.

Installation and mounting
Installation involves inserting the cable into the cable lug and then screwing it into the screw terminal of the switchgear. The precise end machining facilitates cable insertion, while the flat contact surface ensures even distribution of screw force. Crimping is achieved by the screw force, which securely holds the cable inside the lug. Correct installation requires adherence to the specified screw torque to ensure a reliable connection.

Advantages in operation
The cable lug 12SG12 provides a reliable and durable electrical connection, secured by the use of annealed copper and galvanic tinning. The slim design enables optimal space utilisation in compact switchgear. The precise end machining and flat contact surface facilitate installation and ensure secure contact. Its use in switchgear with reduced connection space makes it particularly suitable for modern, compact electrical installations.

General
Degree of protectionGalvanic tinned
MaterialCu according to EN 13600
Connection typepipe cable gland
Conductor cross section240 qmm
ThreadM12
Applicationfor stranded conductors e.g. VDE 0295 class 2
Application rangeSwitchgear with reduced connection area
Manufacturing processnew manufacturing process without material loss
Surface treatmentGalvanic tinned
Contact surfaceplane
End processingprecise
Material conditionannealed material


Please note...
This article contains a copper surcharge of 1,93 EUR. This depends on daily copper prices and weight of included copper. You can inquire the copper price via phone under +49 7666 884990
