Jung RS8REGHE Frame 3-gang AS 583 BF, AS 500 white
|
380,42 EUR |
|||||||||||
|
( 452,70 EUR incl. VAT ) plus delivery charges |
|||||||||||
| Delivery time on requestinfo_outline | |||||||||||
| Lieske Part No.: | 637103 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | RS8REGHE | ||||||||||
| UPC/EAN: | 4011377036345 | ||||||||||
| Weight: | 0.57 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Jung RS8REGHE:
with electronic manual operation and LED status display
8 NO contacts
Intended use
Switching lighting
Switching single-phase fan motors
Switching electrically operated blinds, roller shutters, awnings and similar blinds
Installation on top hat rail in sub-distribution board
Operation using sensor modules, touch sensor modules or non-illuminated installation buttons
Product features
On-site operation: the relay station can be operated using the keypad without any control points being connected.
Control of feedback LEDs on the control points. The relay station has control outputs A1? ... A8? for this purpose.
Switch operation
Touch
operation Blind operation with slat adjustment
Mixed operation Switching, pressing and blinds is possible
Central function Central ON, Central OFF: Joint switching on or off of the load outputs
Parallel switching of two relay stations possible
Nominal voltage: AC 230/240 V ~, 50/60 Hz
Power loss: 12.5 W
Standby power: 0.5 W
Length of control cable: max. 100 m
Number of control points
Sensor module (item no.: SM 1608): max. 4 (also with relay/dimming stations connected in parallel)
Touch sensor modules 24 V AC/DC (normally open): depends on the touch sensor module, note current consumption
Touch sensor module (item no.: 4008 TSM): max. 4 (also with relay/dimming stations connected in parallel)
Control points
Voltage: DC 24 V SELV
Current carrying capacity: ? 80 mA
Switching inputs E1 ... E8
Resistance Ri: 200 kO
Control voltage: DC 24 V SELV
Control outputs A1? ... A8?
Resistance Ra: 330 O
Control voltage: DC 24 V SELV
Current carrying capacity: 10 mA
Connection of mains and load outputs
Connection type: screw terminals
single-wire: 1 x 1.5 ... 4 mm2
fine-stranded without wire end ferrule: 1 x 0.75 ... 4 mm2
fine-stranded with wire end ferrule: 1 x 0.5 ... 2.5 mm2
Connection of switching inputs / control outputs / control points
Connection type: screw terminals
single-wire: 1.5 mm²
fine-stranded without wire end ferrule: 1 mm²
fine-stranded with wire end ferrule: 0.75 mm²
Load outputs A1 ... A8
Contact type: potential-free normally open contact (? contact)
Switching capacity per load output: AC 250 V ~ / 16 AX
Switching current load outputs: ? 80 A
Switching current adjacent load outputs: ? 20 A
Loads per output
Ohmic load: 3000 W
Capacitive load: 16 A / max. 140 µF
Blind/fan motors: 1380 VA
Inrush current: max. 800 A (200 µs)max. 165 A (20 ms)
Lamp loads
Incandescent lamps: 3000 W
HV halogen lamps: 2500 W
LV halogen lamps with
electronic transformers: 1500 W
inductive transformers: 1200 VA
Fluorescent lamps
uncompensated: 1000 W
parallel compensated: 1160 W / 140 µF
Duo circuit: 2300 W / 140 µF Electronic ballast
: type-dependent
Minimum load: AC 12 V, 100 mA
Ambient temperature: ?5 ... +45 °C
Storage temperature: ?25 ... +70 °C
Installation width: 144 mm (8 HP)
Locking time for change of direction: 1 s
Switch-on time for blind operation: 2 min
Type: RS 8 REGHE
