INTELLINET Gigabit PoE+ Media Converter 1000Base-T RJ45 Port to 1000Base-LX SC Single-Mode 20km 12.4 mi. PoE+ Injector
|
75,52 EUR |
|
|
( 89,86 EUR incl. VAT ) ≈ £63.58 | ≈ $84.80 plus delivery charges: 53,00 € |
|
| Delivery time from supplier's stock (ca.) 9 workdaysinfo_outline | |
| In Stock: >10 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 1368476 |
| Mfg Part No: | 508209 |
| UPC/EAN: | 0766623508209 |
| Weight: | 0.788 kg |
| Certificates | |
| Certification | FCC A |
| Features | |
| LED indicators | Activity, Link, PoE, Power |
| Product colour | Black |
| Housing material | Metal |
| International Protection (IP) code | IP30 |
| Internal | |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Network | |
| Maximum data transfer rate | 1000 Mbit/s |
| Converter input interface | 1000Base-T |
| Converter output interface | 1000Base-LX |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Duplex system | Full, Half |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 55 °C |
| Storage temperature (T-T) | -10 - 70 °C |
| Operating relative humidity (H-H) | 5 - 80% |
| Packaging content | |
| AC adapter included | |
| Manual | |
| Performance | |
| Maximum transfer distance | 20000 m |
| Wavelength | 1310 nm |
| Fiber mode structure | Single-mode |
| Fiber cable diameters supported (core/cladding) | 8/125,8.3/125,8.7/125,10/125 µm |
| Ports & interfaces | |
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber ports quantity | 1 |
| Fiber optic connector | SC |
| DC-in jack | |
| Power | |
| Input voltage | 56 V |
| Input current | 0.5 A |
| Total Power over Ethernet (PoE) budget | 30 W |
| Power over Ethernet (PoE) | |
| Weight & dimensions | |
| Width | 70 mm |
| Depth | 95 mm |
| Height | 25 mm |
| Weight | 200 g |
Questions & answers
What is the delivery time of INTELLINET Gigabit PoE+ Media Converter 1000Base-T RJ45 Port to 1000Base-LX SC Single-Mode 20km 12.4 mi. PoE+ Injector?
The article INTELLINET Gigabit PoE+ Media Converter 1000Base-T RJ45 Port to 1000Base-LX SC Single-Mode 20km 12.4 mi. PoE+ Injector is currently in stock
According to our experience the article is ready for dispatch within 9 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Intellinet 508209 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you INTELLINET Gigabit PoE+ Media Converter 1000Base-T RJ45 Port to 1000Base-LX SC Single-Mode 20km 12.4 mi. PoE+ Injector always at the best possible price. We can give you a discount of 2% on INTELLINET Gigabit PoE+ Media Converter 1000Base-T RJ45 Port to 1000Base-LX SC Single-Mode 20km 12.4 mi. PoE+ Injector if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
