CPU Intel Core i5-14400 / LGA1700 / Box 10 cores / 16 threads / 20M Cache content_copy

The Intel Core i5-14400 is a desktop processor of the 14th generation, developed for use in PC systems in the client and home environment. It features an LGA1700 socket and is delivered in box packaging, enabling installation in a standard PC system. The processor is designed for use in computers with motherboards based on LGA1700 socket technology and offers balanced performance for everyday applications, office software, multimedia, and light gaming.

Applications

The Intel Core i5-14400 is designed for use in desktop PCs, particularly for systems used as workstations, multimedia computers, or for light gaming applications. It is suitable for users requiring a balanced combination of performance and energy efficiency. The processor architecture with 10 cores and 16 threads enables parallel processing of multiple tasks, positively impacting system responsiveness during multitasking. The integrated graphics unit Intel UHD Graphics 730 supports display output to monitors via HDMI 2.1, DisplayPort 1.4a, and Embedded DisplayPort 1.4b, allowing the processor to operate without an additional graphics card.

Features and Specifications in Detail

The processor features 10 cores, including 6 Performance cores (P-cores) and 4 Efficiency cores (E-cores). This hybrid architecture enables flexible workload distribution between performance-intensive and energy-efficient tasks. The base frequency is 2.5 GHz, with a maximum turbo frequency reaching up to 4.7 GHz, depending on load and cooling conditions. The integrated cache is 20 MB, enhancing access speed to frequently used data and improving overall system performance. The integrated graphics unit Intel UHD Graphics 730 supports maximum resolutions via the specified interfaces and achieves a maximum dynamic clock frequency of 1550 MHz.

Technology Explained Simply

The processor operates with an LGA1700 socket, specifically developed for the 14th generation of Intel Core processors. Support for DDR4-SDRAM and DDR5-SDRAM enables flexible memory configuration, with the processor supporting up to 192 GB of system memory. The memory architecture is dual-channel, increasing data transfer rates. The PCI-Express slots support versions 4.0 and 5.0, providing high bandwidth for external devices such as graphics cards, SSDs, or network cards. The TDP (Thermal Design Power) is 65 W, indicating moderate heat generation and allowing the use of a standard cooler.

Compatibility and Accessories

The Intel Core i5-14400 is compatible with motherboards supporting the LGA1700 socket. Support for DDR4-SDRAM and DDR5-SDRAM allows flexible memory selection. The integrated graphics unit enables operation without an additional graphics card, with maximum resolution and number of supported connections defined by the specified interfaces (HDMI 2.1, DisplayPort 1.4a, eDP 1.4b). PCI-Express slots supporting versions 4.0 and 5.0 enable connection to modern interfaces and peripheral devices.

Installation and Mounting

Installation is performed by inserting the processor into the LGA1700 socket on the motherboard, with precise alignment ensured by the socket and processor geometry. The box packaging includes the processor and necessary installation documentation. Mounting does not require special tools, although the use of an appropriate heatsink is recommended to maintain operating temperature within the specified range.

Operational Advantages

The Intel Core i5-14400 offers balanced performance for desktop use with good energy efficiency. The hybrid architecture with 6 P-cores and 4 E-cores enables flexible usage under varying workloads. The integrated graphics unit reduces the need for a separate graphics card module, lowering system costs. Support for DDR4 and DDR5 allows flexible memory selection, and PCI-Express support for versions 4.0 and 5.0 ensures high bandwidth for external devices. The TDP of 65 W enables efficient cooling and reduces power consumption during operation.

General
Processor family	Intel Core i5
Socket	LGA1700
Packaging type	Box
Number of cores	10
Number of threads	16
Architecture	6 P-Cores + 4 E-Cores
Base frequency	2,5 GHz
Turbo frequency	4,7 GHz
Cache	20 MB
Integrated graphics	Intel UHD Graphics 730
Graphics outputs	HDMI 2.1, DisplayPort 1.4a, eDP 1.4b
Max. graphics clock frequency	1550 MHz
Memory channels	Dual-channel
Supported memory types	DDR4-SDRAM, DDR5-SDRAM
Max. supported memory	192 GB
PCI-Express versions	4.0, 5.0
TDP	65 W

---
