InLine® Fibre optic simplex cable, FTTH, LC/APC, OS2, white, 30 m content_copy

Connects a fibre outlet to a compatible fibre modemMatching connection: The fibre optic simplex cable connects a fibre outlet to a compatible modem. Its LC/APC plugs at both ends have an 8° polish.
Additional armour: Flexible stainless steel spiral tubing is integrated into the cable, providing additional metal armour for indoor installation.
Discreet cable routing: The white outer jacket blends into light-coloured rooms. Its 3.0 mm ± 0.2 mm diameter allows routing along walls or furniture.
Matching fibre technology: The cable uses OS2 singlemode fibre with 9/125 µm to G657.A2. Connect the LC/APC-to-LC/APC cable to fibre components with matching ports.
Technical documentation: A test report is included with the FTTH cable. The halogen-free outer jacket and specified insertion and return loss values complete its technical features.
The InLine fibre optic cable connects a fibre outlet to a compatible modem. Suitable for FTTH applications where the connection is established inside a building or routed over a longer distance.
If the fibre outlet is not at the desired modem location, the cable bridges the distance. Matching LC/APC connectors are required at both connection points.
The white jacket enables discreet routing in light-coloured rooms, for example along a wall or near a desk.
Available cable lengths adapt the connection to the room layout. If the modem is moved later, a suitable cable length can also be selected.
Intended for fibre cabling with compatible LC/APC components. Check the connectors on your equipment before connection.
Cable type: Fibre optic simplex cable, FTTH
Fibre type: Singlemode, OS2
Fibre core / cladding: 9/125 µm
Fibre specification: I-VH-2E G657.A2
Connectors: LC/APC 8° to LC/APC 8°
Connector polish: APC, 8°
Cable outer diameter: 3.0 mm ± 0.2 mm
Cable construction: Single-fibre
Armour: Flexible stainless steel spiral tubing
Outer jacket: Halogen-free
Jacket colour: White
Insertion loss (IL): Typical insertion loss (IL): Return loss (RL):

60 dB

Operating temperature: -40 to +85 °C
Storage temperature: -40 to +85 °C
Standards: IEC 61034-2, IEC 60332-3, IEC 60754-2, IEC 61754-20
Documentation: Test report included

Features
Cable length	30 m
Fibre optic type	OS2
Connector 1	SC
Connector 2	SC
Connector 1 gender	Male
Connector 2 gender	Male
Connector polish type	APC
Product colour	White
Core diameter	9 µm
Cladding diameter	125 µm
Insertion loss	0.3 dB
Return loss	60 dB
Full duplex
Operational conditions
Operating temperature (T-T)	-40 - 85 °C
Storage temperature (T-T)	-40 - 85 °C
Other features
Dimensions (WxDxH)	9 x 30000 x 9 mm
Packaging content
Test protocol included
Packaging data
Package width	210 mm
Package depth	210 mm
Package height	20 mm
Package volume	900 cm³
Package weight	445 g
Technical data
Height packaging	0.020m
Length packaging	0.210m
Article width	0.90cm
Bending radius (dynamic)	>60mm
Net weight	0.427kg
Weight	0.445kg
Number of fibres	Simplex (FTTH)
Width packaging	0.210m
Side A	SC/APC plug
Outer diameter	3.0mm
Storage temperature	-40 to +85°C
Fibre class	OS2 (9/125µm) G657A2
Colour	White
Cut side B	APC 8°
Cable Ø	3mm
Bending radius (static)	>30mm
Article length	3000.00cm
Variant	APC 8°
Cut side A	APC 8°
Operation temperature	-20 to +80°C
Signal	Network
Side B	SC/APC plug
Packaging volume	0.0009m³
Length	30m
Article height	0.90cm
UL
Test protocol enclosed
Weight & dimensions
Cable diameter	3 mm
Weight	427 g

---
