Inline 76821G
Patchkabel SF/FTP Cat6A grün 0,25 m
|
-12% 1,49 EUR 1,69 EUR |
|||||||||||
|
( 1,77 EUR incl. VAT ) ≈ £1.25 | ≈ $1.67 plus delivery charges: 53,00 € |
|||||||||||
| Delivery time from supplier's stock (ca.) 9 workdaysinfo_outline | |||||||||||
| In Stock: >1000 pieces | |||||||||||
| Datasheet: | file_download Download | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Lieske Part No.: | 2211325 | ||||||||||
| Mfg Part No: | 76821G | ||||||||||
| UPC/EAN: | 4043718294367 | ||||||||||
| Weight: | 0.2 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Inline 76821G:
cable construction S/FTP (PiMf) 4x2xAWG26/7
overall braided shield with paired foil shield
Cable sheath halogen free, LSZH, conform to standards IEC 60332-1-2, IEC 60754-1, IEC 60754-2, IEC 61034 IEC332-1
plug RJ45 (8P8C) with 50µ" gold plated contacts and with special design and latch protection
blue colored plug for easy distinction
For Gigabit and 10 Gigabit applications
up to 500MHz: incl. enclosed test protocol
| Features | |
| Product colour | Green |
| Cable length | 0.25 m |
| Cable standard | Cat6a |
| Cable shielding | S/FTP (S-STP) |
| Connector 1 | RJ-45 |
| Connector 2 | RJ-45 |
| Connector 1 gender | Male |
| Connector 2 gender | Male |
| Jacket material | Low smoke zero halogen (LSZH) |
| Conductor material | Copper |
| AWG wire size | 26 |
| Frequency | 500 MHz |
| Other features | |
| Dimensions (WxDxH) | 15 x 250 x 13 mm |
| Packaging data | |
| Package width | 100 mm |
| Package depth | 140 mm |
| Package height | 15 mm |
| Package weight | 21 g |
| Package volume | 200 cm³ |
| Technical data | |
| Sheath | Halogen-free (LSZH) |
| Max. supported power | 90W |
| Design | Round cable |
| Height packaging | 0.015m |
| Side B | RJ45 plug straight |
| Signal | Network |
| Outer diameter | 6,2mm |
| Wire pairs used for power transmission | The specific method used is determined by the PSE (Power Sourcing Equipment) |
| Diameter | AWG 26 |
| Assignment | 1:1 |
| Operation temperature | -10 to +60°C |
| Article width | 1.50cm |
| Shielding | S/FTP (PiMf) |
| Patch cable category | Cat.6A |
| Net weight | 0.018kg |
| Colour | Green |
| Packaging volume | 0.0002m³ |
| Article length | 25.00cm |
| Data transmission rate | 10Gb/s |
| Type | Cat.6A |
| Length packaging | 0.140m |
| Max. supported PoE standard | 802.3bt |
| Side A | RJ45 plug straight |
| Width packaging | 0.100m |
| Max. supported data transfer rate | 10Gb/s |
| Storage temperature | -20 to +70°C |
| Conductor material | CU (copper) |
| Article height | 1.30cm |
| Weight | 0.021kg |
| PoE/PoE+/PoE++ | |
| UL | |
| Weight & dimensions | |
| Width | 15 mm |
| Depth | 250 mm |
| Height | 13 mm |
| Weight | 18 g |
Questions & answers
What is the delivery time of Inline 76821G Patchkabel SF/FTP Cat6A grün 0,25 m?
The article Inline 76821G Patchkabel SF/FTP Cat6A grün 0,25 m is currently in stock
According to our experience the article is ready for dispatch within 9 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Inline 76821G to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Inline 76821G Patchkabel SF/FTP Cat6A grün 0,25 m always at the best possible price. We can give you a discount of 2% on Inline 76821G Patchkabel SF/FTP Cat6A grün 0,25 m if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduated prizes with every purchase. If you buy a minimum of 50 pieces of Inline 76821G Patchkabel SF/FTP Cat6A grün 0,25 m we can offer you a price of 1,43 EUR per piece. The more you buy, the cheaper the article will be.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
