InLine® 3+1ports USB 3.2 Gen.1 host controller, PCIe, SATA power and LP bracket
|
23,83 EUR |
|
|
( 28,36 EUR incl. VAT ) ≈ £19.95 | ≈ $26.67 plus delivery charges: 55,00 € |
|
| Delivery time from supplier's stock (ca.) 9 workdaysinfo_outline | |
| In Stock: >5 pieces | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 22196909 |
| Mfg Part No: | 76662C |
| UPC/EAN: | 4043718282760 |
| Weight: | 0.131 kg |
Product information for Inline 76662C:
High data rates: Up to 5 Gb/s, backward compatible with USB 2.0 at 480 Mb/s.
Quick setup: Plug and Play on Windows 10/8.x/7/Vista/XP.
Flexible chassis compatibility: Includes low-profile slot bracket for use in slim systems.
Stable operation for USB devices: Up to 5 V/900 mA per port with connected power supply.
The PCIe card adds four USB 3.2 Gen.1 Type-A ports to your computer and creates additional capacity for mass storage, input devices, and other accessories. Thanks to up to 5 Gb/s throughput and backward compatibility with USB 2.0, you benefit from fast transfers while keeping existing devices in use.
In professional IT environments, on-site installations, and service deployments, the card enables straightforward retrofitting without major modifications. It integrates reliably into existing infrastructures of companies and public institutions and is also suitable for compact PCs.
Interface: PCI Express x1, Revision 2.0
Ports: 3x USB 3.2 Gen.1 Type-A external, 1x USB 3.2 Gen.1 Type-A internal
Data rate: up to 5 Gb/s (USB 3.2 Gen.1), up to 480 Mb/s (USB 2.0)
Protocols: UASP, BOT
Chipset: VIA VL805
Compatibility: Backward compatible with USB 2.0 and PCI Express 1.0
Operating systems: Windows 10/8.x/7/Vista/XP 32-/64-bit
Plug and Play: supported
Power output: max. 5 V/900 mA per port (with connected power supply)
Form factor: standard and low-profile, low-profile slot bracket included
Additional connector: SATA
| Features | |
| Plug and Play | |
| Other features | |
| Data transfer rate | 5000 Mbit/s |
| Dimensions (WxDxH) | 100 x 1.31 x 120 mm |
| Packaging data | |
| Package width | 140 mm |
| Package depth | 195 mm |
| Package height | 36 mm |
| Package weight | 72 g |
| Package volume | 1200 cm³ |
| Mounting brackets included | |
| Drivers included | |
| Manual | |
| Ports & interfaces | |
| Host interface | PCIe |
| Output interface | USB 3.2 Gen 1 (3.1 Gen 1) |
| Expansion card form factor | Low-profile |
| Technical data | |
| Packaging volume | 0.0012m³ |
| Article width | 12.00cm |
| Length packaging | 0.195m |
| Article length | 10.00cm |
| Type | Interface card |
| Article height | 2.00cm |
| Width packaging | 0.140m |
| Interface | USB 3.2 Gen.1 |
| Slot | PCIe |
| Connections external | 3x USB-A socket |
| Connections internal | 1x USB-A socket / SATA power |
| Height packaging | 0.036m |
| Net weight | 0.072kg |
| Transmission rate | 5Gb/s |
| USB specification | USB 3.2 Gen.1 |
| Chipset | VIA VL805 |
| Weight | 0.131kg |
| Low Profile | |
| Weight & dimensions | |
| Width | 100 mm |
| Depth | 1.31 mm |
| Height | 120 mm |
| Weight | 2 kg |
Questions & answers
What is the delivery time of InLine® 3+1ports USB 3.2 Gen.1 host controller, PCIe, SATA power and LP bracket?
The article InLine® 3+1ports USB 3.2 Gen.1 host controller, PCIe, SATA power and LP bracket is currently in stock
According to our experience the article is ready for dispatch within 9 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Inline 76662C to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you InLine® 3+1ports USB 3.2 Gen.1 host controller, PCIe, SATA power and LP bracket always at the best possible price. We can give you a discount of 2% on InLine® 3+1ports USB 3.2 Gen.1 host controller, PCIe, SATA power and LP bracket if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
