InLine® interface card M.2 to 4x serial 9-pin connector content_copy

Expansion card for converting M.2 to 4x serial 9-pin connectors
PCIe 3.0 x4 interface with support for high data rates
Automatic lane detection at boot for easy system integration
Onboard LED indicator to display the operating activity
Compatible with Windows and Linux
The InLine® interface card M.2 to 4x serial 9pin connector enables the use of up to four serial interfaces (DB9-9pin) and offers a powerful conversion from M.2 to serial communication. The card is equipped with a PCIe 3.0 x4 interface and supports data rates of up to 4 Gb/s.
The automatic lane detection at boot ensures seamless system integration. The card is powered directly via the PCIe bus (3.3 V). The scope of delivery also includes low-profile slot brackets so that the card can also be used in more compact systems.
Technical data:
Bus type & PCIe: PCIe 3.0 x4 (maximum bandwidth up to 4 Gb/s)
Controller/chipset: ASIX AX99100
Ports – interfaces:1 x M.2 slot (Key M) for the module connection
4 x serial 9-pin connector (DB9-9pin)
Compatible module sizes: 2230, 2242, 2260, 2280
Dimensions: 22 mm x 80 mm (M.2 board)
Operating temperature: -40 °C to +85 °C
Functions:
Automatic lane detection during the boot process
LED indicator for displaying read/write activities
Power supply via PCIe bus (3.3 V)
No driver installation necessary
System requirements: Hardware:
Free PCIe x4 slot (also compatible with x8 or x16 slots)
Motherboard with PCIe 3.0 or higher
Operating system compatibility:
Windows: 11, 10, 8.1, 8, 7
Windows Server: 2012 R2
Linux: from kernel version 2.6
Scope of delivery:
1 x InLine® interface card M.2 to 4x serial 9pin connector
4 x low-profile slot brackets
2 x high-profile slot brackets
4 x DB9 9-pin serial cables (20 cm)
10 x screw
1 x driver CD
1 x user manual (German/English)

Design
Country of origin	Taiwan
Internal
LED indicators
Features
Chipset	ASIX AX99100
Data transfer rate (max)	4 Gbit/s
Operational conditions
Operating temperature (T-T)	-40 - 85 °C
Other features
Dimensions (WxDxH)	80 x 1.68 x 22 mm
Packaging data
Cables included	Serial
Package width	140 mm
Package depth	33 mm
Package height	155 mm
Package weight	44 g
Package type	Hanging box
Mounting brackets included
Drivers included
Manual
Ports & interfaces
Host interface	M.2
Host interface gender	Male
Output interface	Serial
Expansion card standard	PCIe 3.0
Serial ports quantity	4
Serial interface type	9-pin
Power
Power supply input voltage	3.3 V
System requirements
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8, Windows 8.1
Linux operating systems supported	Kernel 2.6.31, Kernel 2.6.33, Kernel 3.12, Kernel 3.17, Kernel 3.3, Kernel 4.6.4, Linux Kernel 5.10, Linux Kernel 5.11, Linux Kernel 5.12, Linux Kernel 5.13, Linux Kernel 5.14, Linux Kernel 5.15, Linux Kernel 5.19, Linux Kernel 5.4, Linux Kernel 5.8, Linux Kernel 5.9, Linux Kernel 6.2, Linux Kernel 6.5
Server operating systems supported	Windows Server 2012 R2
Technical data
Length packaging	0.033m
Transmission rate	4Gb/s
Weight	0.168kg
Interface	Serial
Height packaging	0.155m
Type	Interface card
Chipset	ASIX AX99100
Connections internal	M.2-NVMe-SSD
Connections external	4x 9pin serial
Slot	PCIe
Article height	0.80cm
Width packaging	0.140m
Article width	2.20cm
Net weight	0.044kg
Article length	8.00cm
Low Profile
Technical details
Compliance certificates	TÜV mark, Federal Communications Commission (FCC), CE
Weight & dimensions
Width	80 mm
Depth	1.68 mm
Height	22 mm
Weight	800 g

---
