InLine® USB-A coupler, short, IP68, 2x USB-A socket, shielded content_copy

Compact USB-A coupling: Only 74 mm long – perfect for installations with limited space.
IP68-protected: Robust connection for demanding outdoor and industrial applications.
Data and power: 5 Gb/s transfer rate, 2 A current at 5 V – ideal for data transfer and charging.
Shielded housing: High EMC protection for interference-free connection in critical environments.
Tool-free installation: With screw mechanism and seal – safe, fast, reliable.
The InLine® USB-A cable connector in a short design with
IP68 protection is the ideal solution for USB-A connections under extreme conditions. Its compact length of only 74 mm makes it ideal for confined installation locations, e.g., in outdoor enclosures, machines, or industrial systems.
With a USB-A socket on both sides, the shielded connector is designed for data transfers up to 5 Gb/s and charging with up to 2 A at 5 V. It thus meets all the requirements of a modern USB connection – both for industrial applications and for professional outdoor installations.
Thanks to the integrated screw mechanism, the coupling can be mounted quickly and without tools. The combination of a green sealing ring and rubber seal ensures reliable
IP68 sealing – against dust, moisture, and mechanical stress.
The ideal solution for USB connections in demanding environments where reliability, protection, and compactness are required.
Material: Nylon (PA66)
Thread size: M20
Module: USB-A female/female
Seal: Silicone
Transfer rate: 5 Gb/s
Current: 2 A
Voltage: 5 V
Charging: yes
Protection rating:
IP68
Temperature resistance: -25 °C to +105 °C
Cable diameter: 1.5–4.5 mm, 4.5–7.5 mm

Certificates
Compliance certificates	TÜV mark
Features
Product type	Cable coupler
Product colour	Black
Material	Polyamide, Silicone
Protection features	Dust proof, Waterproof
Connector(s)	USB-A coupler, short, IP68, 2x USB-A socket, shielded
Logistics data
Country of origin	China
Package volume	200 cm³
Packaging content
Quantity per pack	1 pc(s)
Packaging data
Package width	70 mm
Package depth	140 mm
Package height	25 mm
Package weight	42 g
Technical data
Weight	0.042kg
Colour	Black
Side A	USB-A female
Variant	IP68
Net weight	0.036kg
Side B	USB-A female
Height packaging	0.025m
Packaging volume	0.0002m³
Article width	2.50cm
Width packaging	0.070m
Article height	2.50cm
Length packaging	0.140m
Article length	9.00cm
Weight & dimensions
Width	25 mm
Depth	90 mm
Height	25 mm
Weight	36 g

---
