InLine® USB-C coupler, IP68, shielded, socket to plug, 50cm content_copy

50 cm integrated USB-C cable with plug: Female to male – ideal for enclosure mounting or low-loss, direct connections.
With IP68 protection for harsh conditions: The robust design with silicone seal provides reliable protection against moisture and dust.
USB-C performance for data and power: Transfers up to 5 Gb/s and 5 V/2 A – ideal for communication and charging applications.
Shielded against electromagnetic interference: For reliable signals in sensitive technical or industrial environments.
Easy installation: Can be easily integrated into enclosures, technical boxes, or distributors.
The InLine® USB-C cable coupling with 50 cm cable is the ideal solution for applications requiring a weatherproof, robust, and low-loss USB-C connection. The permanently integrated cable with connector reduces the number of transitions – ideal for enclosure installation, embedded systems, or technical field installations.
The system offers IP68 protection against water and dust and, thanks to its silicone seal and robust PA66 housing, is also suitable for permanent outdoor use or in industrial environments. The shielded design prevents interference from electromagnetic fields – perfect for machines, control systems, or sensitive measurement technology, for example.
The cable supports data rates of up to 5 Gb/s and a power supply of 5 V and 2 A. Installation is tool-free via an M20 thread.
This connector is ideal for anyone who needs a high-quality, weatherproof, and shielded USB-C connection with a fixed cable – compact, reliable, and versatile.
Material: Nylon (PA66)
Thread size: M20
Module: USB-C socket/plug
Seal: Silicone
Transfer rate: 5 Gb/s
Current: 2 A
Voltage: 5 V
Charging: Yes
Protection rating: IP68
Temperature resistance: –25 °C to +105 °C

Certificates
Compliance certificates	TÜV mark
Features
Product type	Cable coupler
Product colour	Black
Material	Polyamide, Silicone
Protection features	Dust proof, Waterproof
Logistics data
Country of origin	China
Package volume	200 cm³
Packaging content
Quantity per pack	1 pc(s)
Packaging data
Package width	70 mm
Package depth	140 mm
Package height	30 mm
Package weight	40 g
Technical data
Length packaging	0.140m
Article length	50.00cm
Weight	0.040kg
Side A	USB-C female
Width packaging	0.070m
Article height	2.80cm
Height packaging	0.030m
Net weight	0.034kg
Packaging volume	0.0002m³
Article width	2.80cm
Variant	IP68
Colour	Black
Side B	USB-C male
Weight & dimensions
Width	28 mm
Depth	500 mm
Height	28 mm
Weight	34 g

---
