InLine® USB-C coupler, mini, IP68, shielded, 2x USB-C socket content_copy

IP68-certified protection for harsh environments: Silicone seal and PA66 housing provide reliable protection against water and dust – ideal for outdoor use.
Stable data transmission with USB-C: Supports up to 5 Gb/s – suitable for fast signals in industrial or mobile applications.
Simultaneous power supply possible: Transfers up to 5 V/2 A – perfect for charging points or sensors with USB-C power supply.
Compact format with M20 thread: Fits into standardized housing openings – easy integration into distributors, machines, or panels.
Easy installation: Can be easily integrated into housings, technical boxes, or distributors.
The InLine® USB-C cable coupling Mini with IP68 certification is the ideal solution for robust USB-C connections in industrial, outdoor, and technical environments. Whether in machine housings, distribution cabinets, or mobile applications, this shielded coupling ensures secure data and power connections under demanding conditions.
Thanks to the PA66 plastic housing and a high-quality silicone seal, the connection remains reliably protected even under adverse conditions. The coupler transmits data at up to 5 Gb/s and power at up to 5 V and 2 A – ideal for sensor technology, charging points, or USB-C communication in the field.
The M20 thread allows for easy installation in enclosures or feed-throughs.
Whether for professional installations or tech-savvy users, this USB-C coupling impresses with its versatility, compactness, and durability.
Material: Nylon (PA66)
Thread size: M20
Module: USB-C female/female
Seal: Silicone
Transfer rate: 5 Gb/s
Current: 2 A
Voltage: 5 V
Charging: Yes
Protection rating: IP68
Temperature resistance: –25 °C to +105 °C

Certificates
Compliance certificates	TÜV mark
Features
Product type	Cable coupler
Product colour	Black
Material	Polyamide, Silicone
Protection features	Dust proof, Waterproof
Connector(s)	USB-C coupler, mini, IP68, shielded, 2x USB-C socket
Logistics data
Country of origin	China
Package volume	100 cm³
Packaging content
Quantity per pack	1 pc(s)
Packaging data
Package width	50 mm
Package depth	120 mm
Package height	30 mm
Package weight	25 g
Technical data
Side A	USB-C female
Packaging volume	0.0001m³
Article height	2.50cm
Width packaging	0.050m
Article width	2.50cm
Weight	0.025kg
Height packaging	0.030m
Net weight	0.021kg
Side B	USB-C female
Variant	IP68
Colour	Black
Length packaging	0.120m
Article length	4.00cm
Weight & dimensions
Width	25 mm
Depth	40 mm
Height	25 mm
Weight	21 g

---
