InLine® Gigabit network card, M12 x-coded, PCIe x1, 2.1, PoE+ content_copy

Robust M12 interface for industrial and professional network applications
High data rates 10/100/1000 Mb/s & 2.5 Gb/s (auto-negotiation)
PoE/PoE+ (up to 25.5 W) to power compatible devices
VLAN tagging, PXE boot and Wake-on-LAN support
Standard and low-profile slot brackets for maximum compatibility;for maximum compatibility
The InLine® Gigabit network card was specially developed for robust and reliable network connections in industrial environments. Thanks to the M12 x-coded connection, it offers a secure and resilient connection that is ideal for use in machines, control systems and monitoring solutions. With a data rate of up to 2.5 Gb/s via the PCIe 2.1 x1 interface, it ensures fast and stable transmission of large amounts of data. Thanks to the integrated PoE+ support (IEEE 802.3af/802.3at), connected devices such as surveillance cameras, sensors or access points can be supplied with power directly via the network cable; a separate power source is not required. Additional functions such as Jumbo Frames (up to 16 KB) for more efficient data transmission, VLAN tagging for network segmentation, Wake-on-LAN for remote system startup and remote access to the network;for remote booting of systems and PXE support for network-based boot processes make the card a versatile solution for demanding network environments.
Technical data:
External: 1x M12 socket, 8-pin, x-coded
Internal: 1× PCI Express x1 (2.1), 1 x SATA 15-pin power connector
Bus type: PCIe v2.1, x1 lane (operational in x1, x4, x8, x16 slots)
Chip set: Realtek RTL8125B
Supported protocols: IPv4, IPv6
LED: Indicator for action (green) and connection (orange)
Dimensions: 101.5 mm x 120 mm x 21.5 mm (L x W x H)
Supported IEEE standards:
IEEE 802.3 (Ethernet), IEEE 802.3u (Fast Ethernet), IEEE 802.3ab (Gigabit Ethernet)
IEEE 802.3x (Flow Control), IEEE 802.1Q (VLAN)
IEEE 802.3af (PoE) / 802.3at (PoE+)
IEEE 802.1P Layer 2 Priority Encoding - Prioritize network: Efficiently control QoS
Advanced functions:
Supports PXE (Preboot Execution Environment)
Supports RealWoW (Remote Wake-on-LAN üover the Internet)
Supports crossover detection and automatic correction
Supports Microsoft NDIS5/NDIS6 Checksum Offload (IPv4, IPv6, TCP, UDP)
Jumbo Frames: Up to 16 KB
Environmental conditions:
Operating temperature: 0 °C to 55 °C
Storage temperature: -40 °C to 70 °C
Maximum humidity: 90%
Supported operating systems:
Windows: 11, 10, 8.1, 8, 7 (32/64 bit)
Linux: Native support for Fedora, SUSE, Ubuntu, Red Hat
DOS and Novell

Design
Country of origin	Taiwan
Internal
LED indicators
Features
Chipset	Realtek RTL8125B
Operational conditions
Operating temperature (T-T)	0 - 55 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	0 - 90%
Other features
Connectivity technology	Wired
Dimensions (WxDxH)	100 x 1.42 x 25 mm
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Packaging data
Package width	140 mm
Package depth	195 mm
Package height	40 mm
Package weight	72 g
Package volume	1000 cm³
Mounting brackets included
Ports & interfaces
Host interface	PCI Express
System requirements
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8, Windows 8.1
Other operating systems supported	DOS, Novell
Linux operating systems supported
Technical data
Article length	10.00cm
Transmission rate	2.5Gb/s
Packaging volume	0.0010m³
Length packaging	0.195m
Weight	0.142kg
Type	Network card
Article height	12.00cm
Width packaging	0.140m
Chipset	Realtek RTL8125B
Article width	2.50cm
Connections external	1x M12 socket, 8-pin, X-coded
Connections internal	1x SATA power
Height packaging	0.040m
Net weight	0.072kg
Slot	PCIe
Low Profile
Technical details
Compliance certificates	CE, TÜV mark
Weight & dimensions
Width	100 mm
Depth	1.42 mm
Height	25 mm
Weight	12 kg

---
