InLine® Smart WiFi door/window sensor, white/grey content_copy

Direct WiFi connection without a gateway: The WiFi door sensor connects directly to your 2.4 GHz network and can be quickly integrated into your smart home – without the need for an additional bridge or control centre.
Reliable door and window monitoring: The integrated magnetic contact precisely detects every opening and closing and transmits the status in real time to the Smart Life app for full control.
Customised automations and scenarios: Use the Smart Home Sensor to control lights or other processes when the door is opened and define flexible routines according to your requirements.
Compatible with voice control: The WiFi Window Sensor can be integrated into existing routines with Alexa or Google Assistant and conveniently enhances your smart home security via voice command.
Energy-efficient with long battery life: Thanks to its low standby consumption of only 13 microamperes, the door contact has a service life of up to 2 years with 7 activations per day.
The InLine WiFi door and window sensor expands your smart home with reliable contact monitoring for doors, windows or other moving elements. The sensor operates via WiFi at 2.4 gigahertz and is integrated directly into your existing network. No additional control centre is required.
The sensor unit responds to the magnetic contact supplied. As soon as the door or window opens or closes, the status is updated in the Smart Life app. This allows you to keep track of everything at all times and set up individual automations. For example, lighting or other compatible components can be controlled depending on the opening status.
Thanks to Alexa and Google Assistant support, the Smart Home Sensor can be integrated into voice routines. This increases ease of use and enables flexible everyday use.
Low energy consumption ensures a long battery life. With an average of 7 activations per day, the battery life is up to 2 years. In standby mode, it can even last up to 5 years. The compact design allows for discreet installation on doors, windows or cabinet elements.
Colour: White/grey
Material: ABS+PC plastic
Power consumption: 115-120mA
In standby: 13µA
Signal: WiFi 2.4GHz
WiFi standard: IEEE802.11b/g/n
Range: Up to 45 m (with line of sight)
Operating temperature: 0°-40°C
Operating humidity: 20%-85%
Storage temperature: 0°-60°C
Storage humidity: 0%-90%
Weight: 100 g
Dimensions (LxWxH): Transmitter 71 x 21 x 22 mm
Dimensions (L x W x H): Magnet 40 x 11 x 11 mm
Battery: 1 x CR2
Approx. service life: 2 years (at 7 activations per day)
Approx. service life: 5 years in standby mode
App: Smart Life
Compatible with: Amazon Alexa and Google Assistant

Features
Connectivity technology	Wireless
Interface	WLAN
Operating frequency	2400 MHz
Transmission distance	45 m
Suitable for	Door/Window
Security algorithms	WPA, WPA2
Product colour	White
Detection distance	45 m
Housing material	Acrylonitrile butadiene styrene (ABS), Plastic
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 85%
Packaging content
Number of products included	1 pc(s)
Packaging data
Package width	85 mm
Package depth	97 mm
Package height	50 mm
Package weight	60 g
Power
Battery type	CR2
Number of batteries supported	1
Technical data
Weight	0.060kg
WiFi signal	2.4GHz
Width packaging	0.085m
Type	Door/window sensor
Article width	2.00cm
Length packaging	0.097m
Net weight	0.020kg
WiFi standard	IEEE802.11b/g/n
Height packaging	0.050m
Article height	2.40cm
WiFi security	WPA/WPA2 encryption
Range (approx.)	In visual sight up to 45m
Packaging volume	0.0005m³
Article length	7.20cm
Weight & dimensions
Transmitter width	2.1 cm
Transmitter depth	7.1 cm
Transmitter height	2.2 cm
Width	200 mm
Depth	720 mm
Height	240 mm
Weight	20 g

---
