InLine® PoE+ Gigabit Network Switch 24 port, 1 Gb/s, 2xSFP,48,3 cm ( 19 inch )1U(incl. brackets) content_copy

PoE++ switch with 16 ports and SFP uplink for flexible power and data supplySupply high-power devices: PoE++ up to 60 W (ports 1-4), PoE+ up to 32 W (ports 5-16), 300 W budget.
Safely bridge long distances: 2x SFP for fiber uplinks at 1000 Mb/s.
Simplify rack deployment: 19 inch, 1 U, mounting brackets included; 3 fans for stable cooling.
Monitor operation and diagnostics: LCD with real-time PoE status, password-protected menu.
Protect ports and devices: Protection against overload, overvoltage, and overheating at each port; ± 6 kV surge protection.
This PoE++ Gigabit switch combines data transmission and power supply on 16 RJ45 ports with 10/100/1000 Mb/s. Four ports deliver up to 60 W, the other twelve up to 32 W; the 300 W PoE budget and the 330 W total power also cover power-hungry devices. Two SFP slots connect fiber at 1000 Mb/s and help bridge longer distances. The LCD display provides real-time PoE status information, the password-protected menu supports secure administration. Integrated protection functions increase operational reliability.
In professional IT environments, in on-site installations, and in existing infrastructures of companies and public institutions, the switch reduces the need for power outlets and simplifies placement of IP cameras (including models with heater), wireless access points, or VoIP endpoints. Features such as store-and-forward, jumbo frames, and an 8K MAC table support reliable performance; the 19 inch 1 U rack form factor facilitates integration.
Interfaces: 16x RJ45 10/100/1000 Mb/s (Auto-MDI/MDI-X), 2x SFP 1000 Mb/s
PoE ports: 16 (ports 1-4 PoE++, ports 5-16 PoE+)
PoE power: ports 1-4 max. 60 W, ports 5-16 max. 32 W
PoE budget: 300 W
Total power: 330 W
Standards: IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x, 802.3af, 802.3at, 802.3bt, 802.3az
Display: LCD, real-time PoE status
Network cables: Cat.5e/6/6A/8.1 up to 100 m
1000Base-X: MMF, SMF
MAC address table: 8K, automatic learning, automatic updates
Jumbo frame: 9216 bytes
Packet buffer: 4.1 Mbit
Forwarding mode: store-and-forward
Packet forwarding rate: 26.78 million packets per second
Bandwidth: 36 Gbit
Surge protection: ± 6 kV
Number of fans: 3
Dimensions: 440 x 232 x 45 mm
Weight: approx. 3.2 kg
Input voltage: 100-240 V AC, 50/60 Hz
Operating temperature: -10-60 °C
Storage temperature: -40-70 °C
Operating humidity: 10-90 % non-condensing
Storage humidity: 5-90 % non-condensing
Rack mounting: 19 inch, 1 U, mounting brackets included

Data transmission
Forwarding rate	26.78 Mpps
MAC address table	8000 entries
Jumbo frames	9216
Transmission method	Store-and-forward
Packet buffer memory	4.1 MB
Jumbo frames support
Design
Form factor	1U
Product colour	Black
Number of fans	3 fan(s)
Rack mounting
LED indicators
Network
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Cable types supported	Cat5e, Cat6, Cat6a, Cat8.1
Ethernet LAN data rates	10,100,1000 Mbit/s
10G support
Auto MDI/MDI-X
MAC address auto-learning supported
Operational conditions
Operating temperature (T-T)	-10 - 60 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 90%
Optical fiber
Fiber ethernet cabling technology	1000BASE-X
Other features
Dimensions (WxDxH)	440 x 37.75 x 230 mm
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Ethernet LAN (RJ-45) ports	16
Packaging data
Package width	350 mm
Package depth	500 mm
Package height	95 mm
Package volume	16700 cm³
Package weight	3.12 kg
Performance
Maximum data transfer rate	1000 Mbit/s
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	16
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
SFP module slots quantity	2
Power connector	AC-in jack
Power
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	330 W
Power supply included
Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity	8
Total Power over Ethernet (PoE) budget	300 W
Power over Ethernet (PoE)
Technical data
Article height	4.50cm
PoE	PoE++
Number of ports	16
Length packaging	0.500m
Article length	44.00cm
Net weight	3.125kg
Height packaging	0.095m
Article width	23.00cm
Type	19" switch
Fibre optics	2x SFP
Weight	3.775kg
Width packaging	0.350m
Packaging volume	0.0167m³
Transmission speed	10/100/1000Mb/s
Fans
Managed
Weight & dimensions
Width	440 mm
Depth	37.8 mm
Height	230 mm
Weight	4.5 kg

---
