InLine® Desk Bracket for 4x TV / LED / TFT Display up to 81cm 32" max. 9kg content_copy

Mount four displays ergonomically and in a space-saving way at the deskBundle four displays efficiently: Save space and create a tidy multi-screen workspace.
Ergonomic alignment: tilt +/- 45 °, 360 ° rotation and height adjustment up to approx. 86 cm for a comfortable viewing position.
Flexible mounting: attachment via screw clamp to the tabletop up to approx. 85 mm or through the tabletop up to approx. 40 mm.
Wide compatibility: VESA 75x75 and 100x100 mm, for displays from 43 cm to 81 cm and up to 9 kg per display.
The desk mount combines four LCD/LED displays at one workstation and supports an ergonomic, efficient arrangement. Joints enable precise alignment by tilting, rotating, and height adjustment, allowing you to optimally adapt viewing angles and distances. The stable attachment to the desk provides a secure hold.
In professional IT environments and during on-site deployments, the flexible mounting accelerates a clean implementation with little effort. Multi-screen workstations can also be set up quickly and neatly within existing infrastructures of companies and public institutions.
Number of monitors: 4
Display size: 43 cm (17") to 81 cm (32")
VESA: 75x75, 100x100 mm
Tilt: +/- 45 °
Rotation: 360 °
Height adjustment: up to approx. 86 cm
Mounting: screw clamp or through-desk mounting
Tabletop thickness: up to approx. 85 mm (clamp), up to approx. 40 mm (through-desk)
Load capacity: max. 4x 9 kg
Scope of delivery: desk mount with screw clamp, screw set M4/M5, 2x hex keys, assembly guide

Design
Product colour	Black
Orientation	Landscape/Portrait
Ergonomics
Height adjustment range	0 - 860 mm
Tilt angle range	-45 - 45°
Angle of rotation	360°
Height adjustment
Tilt adjustment
Rotating
Logistics data
Country of origin	Taiwan
Mounting
Minimum screen size	43.2 cm (17")
Number of displays supported	4
Maximum weight capacity (per display)	9 kg
Maximum screen size	81.3 cm (32")
Mounting	Clamp/Grommet
Mounting type	Desk
Minimum VESA mount	75 x 75 mm
Maximum VESA mount	100 x 100 mm
Clamp mount desk thickness (max)	8.5 cm
Grommet mount desk thickness (max)	4 cm
Other features
Dimensions (WxDxH)	800 x 1000 x 100 mm
Compliance certificates	TÜV mark
Packaging content
Clamp included
VESA mount included
Mounting kit
Manual
Packaging data
Package width	305 mm
Package depth	440 mm
Package height	150 mm
Package volume	4200 cm³
Package weight	7.44 kg
Technical data
Packaging volume	0.0042m³
Article height	10.00cm
Number of monitors	4
Colour	Black
Weight	7.444kg
VESA	75x75 / 100x100mm
Suitable for	Displays from 43cm (17") to 81cm (32")
Width packaging	0.305m
Height packaging	0.150m
Article width	80.00cm
Load (max.)	9kg
Length packaging	0.440m
Article length	100.00cm
Tiltable	+/-45°
Net weight	7.000kg
Hinged/swivel arm
Rotatable
Gas spring
Adjustable in height
Weight & dimensions
Width	800 mm
Depth	1000 mm
Height	100 mm
Weight	7 kg

---
