iiyama ProLite open-frame LCDs, 54.6cm (21.5''), Projected Capacitive, 10 TP, Full HD, USB, kit (USB), black
|
424,99 EUR 442,70 EUR |
|
|
( 505,74 EUR incl. VAT ) ≈ £355.72 | ≈ $473.86 plus delivery charges: 100,00 € |
|
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 2112892 |
| Mfg Part No: | TF2238MSC-B1 |
| Weight: | 6.422 kg |
Product information for Iiyama TF2238MSC-B1:
touch monitor (open-frame, 16:9), 54.6cm (21.5''), Projected Capacitive, multi touch (10 points), 1920x1080 pixels, VESA mount (100x100 mm), response time: 5ms, brightness 600cd, viewing angle 178/178°(H/V), 1000:1, USB (2x), display-port, HDMI, incl.: cable (USB, HDMI), power supply unit, power cable, QSG, colour: black
| Design | |
| Product colour | Black |
| Front bezel colour | Black |
| Glass thickness | 3.6 mm |
| Display | |
| Display diagonal | 53.3 cm (21") |
| Display resolution | 1920 x 1080 pixels |
| HD type | Full HD |
| Native aspect ratio | 16:9 |
| Display technology | LED |
| Panel type | IPS |
| Touchscreen technology | Projected capacitive system |
| Number of simultaneous touchpoints | 10 |
| Display brightness (typical) | 600 cd/m² |
| Display brightness | 525 cd/m² |
| Response time | 5 ms |
| Response time measurement type | GTG (Gray to Gray) |
| Contrast ratio (typical) | 1000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 16.7 million colours |
| Pixel pitch | 0.249 x 0.249 mm |
| Horizontal scan range | 30 - 83 kHz |
| Viewable size, horizontal | 47.9 cm |
| Viewable size, vertical | 26 cm |
| Display diagonal (metric) | 54.5 cm |
| Surface hardness | 7H |
| Touchscreen | |
| Ergonomics | |
| Panel mounting interface | 100 x 100 mm |
| On Screen Display (OSD) languages | Traditional Chinese, German, English, French, Japanese, Dutch, Polish, Russian |
| VESA mounting | |
| On Screen Display (OSD) | |
| Multimedia | |
| Number of speakers | 2 |
| RMS rated power | 4 W |
| Built-in speaker(s) | |
| Network | |
| Wi-Fi | |
| Ethernet LAN | |
| Other features | |
| International Protection (IP) code | IP1X |
| Compatible operating systems | All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section. |
| Placement supported | Indoor |
| Brightness | 525 cd/m² |
| Active display area (W x H) | 479 x 260 mm |
| USB ports quantity | 2 |
| Weight | 5.1 kg |
| Height | 300 mm |
| User controls | Picture adjust (brightness, contrast, i-Style color, adv. contrast, ECO mode, OD, X-Res), color settings (gamma, RGB range, color. temp.), image settings (video mode adjust, blue light reducer, sharp & soft), OSD (H. pos., V. pos., time, background, rotate, language, display information), extra (reset, DDC/CI, signal select, volume, mute, led, opening logo, touch switch) |
| Touch method | stylus, finger, glove |
| Width | 512.5 mm |
| Depth | 47 mm |
| Control panel | Menu, Scroll up/ Eco, Scroll down/ Volume, Enter/ Input select, Power |
| Compliance certificates | CE, cTUVus, EAC, REACH, RoHS, TÜV mark, UKCA, WEEE |
| Mean time between failures (MTBF) | 50000 h |
| Certification | CE, TÜV-Bauart, EAC, RoHS support, ErP, WEEE, REACH, UKCA |
| Built-in processor | |
| Packaging content | |
| Cables included | AC, USB, HDMI |
| Quick start guide | |
| Packaging data | |
| Package width | 572 mm |
| Package depth | 112 mm |
| Package height | 364 mm |
| Package weight | 6.4 kg |
| Performance | |
| Low Blue Light technology | |
| Ports & interfaces | |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| USB hub version | 3.2 Gen 1 (3.1 Gen 1) |
| Number of downstream ports | 2 |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| Built-in USB hub | |
| USB Touch port | |
| DVI port | |
| HDCP | |
| Power | |
| Energy efficiency class (SDR) | D |
| Energy efficiency class (HDR) | Not available |
| Energy consumption (SDR) per 1000 hours | 12.9 kWh |
| Power consumption (typical) | 17 W |
| Power consumption (standby) | 1.5 W |
| Power consumption (off) | 0.3 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power supply type | Internal |
| Sustainability | |
| Sustainability certificates | ErP |
| Weight & dimensions | |
| Width (with stand) | 512.5 mm |
| Depth (with stand) | 47 mm |
| Height (with stand) | 300 mm |
| Weight (with stand) | 5.1 kg |
| Bezel width (side) | 1.7 cm |
| Bezel width (top) | 1.98 cm |
| Bezel width (bottom) | 1.98 cm |
Questions & answers
What is the delivery time of iiyama ProLite open-frame LCDs, 54.6cm (21.5''), Projected Capacitive, 10 TP, Full HD, USB, kit (USB), black?
The article iiyama ProLite open-frame LCDs, 54.6cm (21.5''), Projected Capacitive, 10 TP, Full HD, USB, kit (USB), black is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Iiyama TF2238MSC-B1 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you iiyama ProLite open-frame LCDs, 54.6cm (21.5''), Projected Capacitive, 10 TP, Full HD, USB, kit (USB), black always at the best possible price. We can give you a discount of 2% on iiyama ProLite open-frame LCDs, 54.6cm (21.5''), Projected Capacitive, 10 TP, Full HD, USB, kit (USB), black if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
