HP 3XB78A#B19 Designjet T2600 PostScript 91,4 cm ( 36 inch ) (freight shipping) content_copy

The HP DesignJet T2600 multifunction printer is a large-format printer for professional use in office and engineering environments. It combines printing and scanning functions in a compact device and is specifically designed for processing technical drawings, architectural plans, graphics, and other large-format documents. The device is based on Thermal Inkjet technology and offers a maximum print resolution of 2400 x 1200 DPI, ensuring sharp lines and detailed color reproduction. The print colors include Cyan, Photo black, Matte black, Magenta, and Yellow, with six print cartridges ensuring precise color reproduction. The print heads are designed as a single unit, simplifying maintenance and replacement.

Applications include architecture offices, engineering offices, graphic designers, and other departments requiring high-quality large-format documents. The maximum print size is A0 (841 x 1189 mm), with support for custom formats ranging from 210 x 279 mm to 914 x 1219 mm. The device is suitable for various media types, including coated paper, semi-matte paper, glossy paper, bond paper, photo paper, matte paper, heavy paper, and satin paper, enabling flexible use. Support for ISO A-formats from A0 to A4 expands its application possibilities.

Functions and equipment in detail include an integrated scanning system with CIS technology and an optical scan resolution of 600 x 600 DPI. The device can scan documents up to 15 m in length and offers functions such as Scan to E-Mail and Scan to USB. The printing and scanning functions are controlled via a 15.6-inch touchscreen, enabling intuitive operation. The print speed reaches up to 180 A1 pages per hour in continuous printing, with an integrated stacking function enabling automatic stacking. Support for PostScript 3, PDF 1.7, HP-GL/2, TIFF, JPEG, HP-RTL, and CALS G4 as page description languages ensures compatibility with common CAD and graphic programs.

Technology explained simply shows that the printer features an internal storage capacity of 500 GB (HDD), used for temporary storage of print jobs and files. The total storage capacity amounts to 128000 MB. Power supply is via 100–240 V AC at a frequency of 50/60 Hz. In standby mode, power consumption is 32 dB, in sleep mode 10 W, and when switched off 0.3 W. The operating temperature ranges from 5 to 35 °C, with relative humidity during operation between 20 and 80 %.

Compatibility and accessories include support for Windows and Mac operating systems. Printer control is via Ethernet/LAN and Wi-Fi Direct, with HP ePrint also available for mobile print jobs. The printers are designed for use with print cartridges equipped with a new or remanufactured HP chip. Dynamic security blocks print cartridges with chips not from HP. Firmware updates ensure the effectiveness of these measures. The integrated Adobe PDF Print Engine ensures highest accuracy in reproducing fine details, especially in PDF files with special fonts, PANTONE® colors, soft gradients, overprinting, and transparency.

Installation and mounting are carried out using the included hardware: the printer is delivered with a printer stand and media tray, a spindle, print heads, introduction cartridges, user manual, and power cables. The software includes HP Click, HP mobile, ePrint, iOS/Android support, plus the HP Smart app for mobile, HP Web Jetadmin, HP JetAdvantage Security Manager, and HP Click Driver for Windows 11. Installation is performed using the included software and network connection.

Operational advantages include the compact design, minimizing space requirements, and quiet operation with up to 87 % less noise generation compared to competing products. The integrated stacking function and support for two media rolls (on models with dual-roll function) increase efficiency. Usability is enhanced by intuitive touchscreen operation and mobile device support via the HP Smart App. Security features such as HP Secure Boot, whitelisting, and secure user authentication protect the network and confidential documents. Certification to Class A (including FCC, ICES, EMC, ACMA, RSM, CCC, VCCI, KCC) ensures electromagnetic compatibility. The device is equipped with ENERGY STAR certification, confirming its energy efficiency.

The device is designed for use in office environments and offers high productivity while ensuring security and user-friendliness. The combination of printing and scanning functions, support for various file formats, and integrated security make the HP DesignJet T2600 a powerful solution for professional large-format applications.

Brand-specific features
HP ePrint
HP Dynamic security
Copying
Copier resize	25 - 400%
Logistics data
Harmonized System (HS) code	84433210
Operational conditions
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80%
Storage temperature (T-T)	-25 - 55 °C
Other features
Electromagnetic compatibility	Compliant with Class A requirements, including: USA (FCC rules), Canada (ICES), EU (EMC Directive), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI), Korea (KCC)
UNSPSC-code	43212107
All-In-One-multitasking
Packaging data
Package width	1477 mm
Package depth	767 mm
Package height	800 mm
Package weight	137 kg
Bundled software	HP Click, HP mobile, ePrint and iOS/Android support plus the HP Smart app for mobile, HP Web Jetadmin, HP JetAdvantage Security Manager, HP Click Driver for Windows 11
Cartridge(s) included
Manual
Paper handling
Custom media sizes	210 x 279 to 914 x 1219 mm
Maximum print size	A0 (841 x 1189 mm)
Paper tray media types	Coated paper, Semi-glossy paper, Glossy paper, Bond paper, Photo paper, Matte paper, Heavy paper, Satin paper
ISO A-series sizes (A0...A9)	A0, A1, A2, A3, A4
Roll paper
Performance
Product colour	White
Internal memory	128000 MB
Internal storage capacity	500 GB
Storage media	HDD
Sound power level (standby)	32 dB
Country of origin	China
Certification	Compliant with Class A requirements, including: USA (FCC rules), Canada (ICES), EU (EMC Directive), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI), Korea (KCC)
HP segment	Business
Ports & interfaces
Mobile printing technologies	HP ePrint
Wi-Fi
Ethernet LAN
USB port
Direct printing
Wi-Fi Direct
Power
Power consumption (PowerSave)	120 W
Power consumption (off)	0.3 W
Power consumption (sleep)	10 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Printing
Print resolution colour	2400 x 1200 DPI
Print technology	Thermal inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	6
Page description languages	PostScript 3, PDF 1.7, HP-GL/2, TIFF, JPEG, HP-RTL, CALS G4
Printing colours	Cyan, Photo black, Matte black, Magenta, Yellow
Print head	1
Colour
Scanning
Scanning	Colour scanning
Optical scanning resolution	600 x 600 DPI
Maximum scan resolution	600 x 600 DPI
Scan technology	CIS
Scan to	E-mail, USB
Maximum scan length	15 m
Sustainability
Sustainability certificates	ENERGY STAR
Sustainability compliance
System requirements
Windows operating systems supported
Mac operating systems supported
Technical details
Box contents	HP DesignJet T2600 Multifuntion Printer, printer stand and media bin, 15.6" touchscreen, spindle, printheads, introductory ink cartridges, user guide, power cords
Weight & dimensions
Width	1390 mm
Depth	760 mm
Height	1240 mm
Weight	106 kg

---
