HELU TOPSERV® 110 HELUKABEL servo cable (4G1,5+(2x1)) Standard length: 500 M

Technical data:

Special PUR drag chain cable based on DIN VDE 0295, 0250, DIN VDE 0285-525-1-1/DIN EN 50525-1
Temperature range moving -30°C to +80°C fixed -40°C to +80°C
Nominal voltage power cores U0/U 600/1000 V control cores U0/U 300/500 V
Test voltage power cores 4000 V control cores 1000 V
Current carrying capacity according to DIN VDE 0298-4
Insulation resistance min. 20 MOhm x km
Minimum bending radius moving 7.5x cable Ø fixed 4x cable Ø
Coupling resistance max. 250 Ohm/km
Structure:
Bare copper wire, according to DIN VDE 0295 class 6, extra fine wire
Core insulation made of halogen-free PP
core identification power cores Core 1: black with imprint U/L1/C/L+ Core 2: black with imprint V/L2 Core 3: black with imprint W/L3/D/L- Control cores TOPSERV 110 Core 1 black with imprint BR1 Core 2 black with imprint BR2 TOPSERV 120 Pair 1 black with numbers no. 5+6 Pair 2 black with numbers no. 7+8
Protective conductor GN-GE
Shielding of control cores in pairs, tinned drain wire and tinned copper braid
Control cores in pairs and twisted with the power cores in layers
Foil banding
Overall shielding made of tinned copper braid, optical coverage min. 80%
Fleece wrapping
Outer jacket made of PUR
Jacket color: petrol (RAL 5018)
Properties:
Low capacitance due to use of PP as core insulation
PUR jacket has low adhesion, hydrolysis and microbe-resistant, halogen-free
Due to EMC compatibility, i.e. interference immunity, the highly flexible cables have an additional overall shield
The materials used in production are silicone and cadmium-free and free from substances that impair paint wetting
Use:
In these cables, the power wires are ideally combined with the control wires for the braking function and thermal protection. Precise servo motors, as used today in many areas of high-tech manufacturing processes, require high-quality, reliable and durable cables. These requirements are met to a high degree, as are those of electromagnetic compatibility (EMC). They can also be used as drag chain cables. Production is based on the specifications of well-known servo drive and control manufacturers and in accordance with various VDE standards. Use for the SIMODRIVE system. EMC = Electromagnetic Compatibility To optimize the EMC properties, we recommend contacting the copper braid on both sides and over a large area all around.
Standard lengths: 100 m, 500 m, 1000 m
Technical changes reserved.
Type: TOPSERV® 110

The item price shown refers to 500 meters Helukabel 71491-500
