Helukabel 20035 HELU TRONIC-CY 10x0.25qmm gray data and computer cable
|
1,71 EUR |
|||||||||||
|
incl. 0,42 EUR copper surcharge ( 2,03 EUR incl. VAT ) plus delivery charges |
|||||||||||
| Delivery time on requestinfo_outline | |||||||||||
| Lieske Part No.: | 1323071 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 20035 | ||||||||||
| UPC/EAN: | 4060892088513 | ||||||||||
| Weight: | 0.12 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Helukabel 20035:
Technical data:
Special PVC data cable based on DIN VDE 0812Temperature range moving -5°C to +80°C stationary -40°C to +80°C
Peak operating voltage (not for high-voltage installation purposes) 0.14 mm² 350 V = 0.25 mm² 500 V
Test voltage core/core 1200 V core/shield 800 V
Breakdown voltage min. 2400 V
Operating capacitance at 800 Hz core/core 0.14 mm² approx. 120 pF/m core/core 0.25 mm² approx. 150 pF/m core/shield 0.14 mm² approx. 240 pF/m core/shield 0.25 mm² approx. 270 pF/m
Inductance approx. 0.65 mH/km Characteristic
impedance approx. 78 Ohm
coupling resistance max. 250 Ohm/km
Minimum bending radius moving 10x cable Ø not moving 5x cable Ø
Radiation resistance up to 80x106 cJ/kg (up to 80 Mrad)
Structure:
Bare copper wire, from 0.5 mm² in accordance with DIN VDE 0295 cl.5, fine-stranded, BS 6360 cl.5, IEC 60228 cl.5
Strand structure at: 0.14 mm² approx. 18x0.1 mm 0.25 mm² approx. 14x0.15 mm 0.34 mm² = 7x0.25 mm
Core insulation made of special PVC
Core marking based on DIN 47100, without color repetition
Cores stranded in layers with optimal lay lengths
Foil wrapping
Drain wire, tinned copper
Shielding braid made of tinned copper wires approx. 85% coverage
Outer jacket made of special PVC
Jacket color: gray (RAL 7001) with meter marking
Properties:
Largely oil-resistant, oil/chemical resistance
The materials used in production are silicone and cadmium-free and free from substances that impair paint wetting
Tests:
PVC self-extinguishing and flame-retardant in accordance with DIN VDE 0482-332-1-2, DIN EN 60332-1-2, IEC 60332-1-2
Notes:
Also available with paired core stranding, see HELUKABEL-PAAR-TRONIC-CY
For 1-core cables, shield made of wrapping (LiY-DY).
Unshielded analogue type: TRONIC (LiYY)
Use:
For flexible use with free movement without tensile stress and without forced movement in dry, damp and wet rooms, but not outdoors, as control and signal cables in the milliampere range for computers, control and regulating devices, scales, etc. Due to the extremely small external diameter, particularly suitable for subminiature plugs, electronic devices, etc. These cables with copper shielding are ideal for interference-free data and signal transmission for measurement, control and regulating technology. EMC = Electromagnetic Compatibility To optimize the EMC properties, we recommend contacting the copper braid on both sides and over a large area all around.
Standard lengths: 100 m, 500 m, 1000 m
Subject to technical changes.
Type: TRONIC-CY 10X0,25 QM
The final cable weight will be determined before invoicing. The calculation is based on the copper content and any additional weight due to drums, pallets, or outer packaging. Prices are subject to this subsequent calculation.
Please note that for cables, that are not in stock and must be produced, the manufacturer may need an order of a minimum length that can be 5-10km depending on cable type!
