Helukabel 16418 F-CY-JZ 4G2, 5qmm TR , PVC control cable with copper shielding gray
|
3,55 EUR |
|||||||||||
|
incl. 1,10 EUR copper surcharge ( 4,22 EUR incl. VAT ) plus delivery charges |
|||||||||||
| Delivery time on requestinfo_outline | |||||||||||
| Lieske Part No.: | 311868 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 16418 | ||||||||||
| UPC/EAN: | 4060892022999 | ||||||||||
| Weight: | 0 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Helukabel 16418:
Technical data:
Special PVC hose cable based on DIN VDE 0285-525-2-51 / DIN EN 50525-2-51Temperature range moving -10°C to +80°C stationary -40°C to +80°C
Nominal voltage U0/U 300/500 V
Test voltage core/core 4000 V core/shield 2000 V
Breakdown voltage min. 8000 V
Insulation resistance min. 20 MOhm x km
Operating capacity varies depending on conductor cross-section for 0.5 to 2.5 mm²: core/core approx. 150 nF/km core/shield approx. 270 nF/km
Coupling resistance max. 250 Ohm/km
Minimum bending radius moving 10x cable Ø stationary 5x cable Ø
Radiation resistance up to 80x106 cJ/kg (up to 80 Mrad)
Structure:
Bare copper wire, in accordance with DIN VDE 0295 cl.5, fine-stranded, BS 6360 cl.5, IEC 60228 cl.5
Core insulation made of special PVC
Core identification in accordance with DIN VDE 0293 Black cores with continuous white numbering Cores stranded
in layers with optimal lay lengths Separating
film
Shielding braid made of tinned copper wires, coverage approx. 85%
Outer jacket made of special PVC
Jacket color: gray (RAL 7001) with meter marking
Properties:
Largely oil-resistant, oil/chemical resistance
The materials used in production are silicone and cadmium-free and free of substances that impair paint wetting
Tests:
PVC self-extinguishing and flame-retardant in accordance with DIN VDE 0482-332-1-2, DIN EN 60332-1-2, IEC 60332-1-2 (corresponds to DIN VDE 0472 Part 804 test type B)
Notes:
'Cleanroom qualified\lashunshielded analogue type: JZ-500
Use:
For medium mechanical stress for flexible application with free movement without tensile stress and without forced movement in dry, damp and wet rooms, but not outdoors, as a control cable in control and regulation technology, in tool and machine construction, in computer systems, in heating and air conditioning technology, in plant construction and as a signal cable in electronics. Instead of a complex PVC inner jacket, a stabilizing separating film is used between the core assembly and the braid. It significantly reduces the outer diameter, which results in smaller bending radii, lower weight, etc. The high shielding density ensures interference-free transmission of signals or impulses. The ideal interference-protected control cable for the above purposes. EMC = Electromagnetic Compatibility In order to optimize the EMC properties, we recommend a large-area all-round contact on both sides of the copper braid.
Standard lengths: 50 m, 100 m, 500 m, 1000 m
Technical changes reserved.
Type: F-CY-JZ 4G2,5 TR
The final cable weight will be determined before invoicing. The calculation is based on the copper content and any additional weight due to drums, pallets, or outer packaging. Prices are subject to this subsequent calculation.
Please note that for cables, that are not in stock and must be produced, the manufacturer may need an order of a minimum length that can be 5-10km depending on cable type!
Questions & answers
What is the delivery time of Helukabel 16418 F-CY-JZ 4G2, 5qmm TR , PVC control cable with copper shielding gray?
The article Helukabel 16418 F-CY-JZ 4G2, 5qmm TR , PVC control cable with copper shielding gray is currently not in stock und muss auftragsbezogen bestellt werden.
According to our experience the article is ready for dispatch within 8 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Helukabel 16418 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Helukabel 16418 F-CY-JZ 4G2, 5qmm TR , PVC control cable with copper shielding gray always at the best possible price. We can give you a discount of 2% on Helukabel 16418 F-CY-JZ 4G2, 5qmm TR , PVC control cable with copper shielding gray if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduation prizes with every purchase. If you buy a minimum of 50 meters of Helukabel 16418 F-CY-JZ 4G2, 5qmm TR , PVC control cable with copper shielding gray we can offer you a price of 3,44 EUR per piece. The more you buy, the cheaper the article will be.
You can also send us a price proposal for your desired quantity of Helukabel 16418 F-CY-JZ 4G2, 5qmm TR , PVC control cable with copper shielding gray via the form price proposal. Enter your name, contact details, price and quantity you need. Our sales team will then send you a good quotation immediately.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
