Helukabel 14090 HELU OB-BL-PAAR-CY 3x2x0,75qmm Blue Intrinsically Safe Control Cable PVC
|
3,36 EUR |
|||||||||||
|
incl. 0,72 EUR copper surcharge ( 4,00 EUR incl. VAT ) plus delivery charges |
|||||||||||
| Delivery time on requestinfo_outline | |||||||||||
| Lieske Part No.: | 2131000 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 14090 | ||||||||||
| UPC/EAN: | 4060892079757 | ||||||||||
| Weight: | 0.12 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Helukabel 14090:
Technical data:
Special PVC hose line with blue sheath for potentially explosive areas with ignition type -i- for intrinsically safe systems, according to DIN EN 60079-14 or IEC 60079-14 section 12.2.2. (VDE 0165 Part 1)Conductor resistance at 0.5 mm² 37.8 Ohm/km at 0.75 mm² 25.3 Ohm/km
Temperature range moving -10°C to +80°C stationary -30°C to +80°C
Peak operating voltage (not for high-current installation purposes) 900 V
Test voltage core/core 2000 V core/shield 1000 V
Breakdown voltage min. 4000 V
Insulation resistance min. 20 MOhm x km
Operating capacitance core/core approx. 105 nF/km core/shield approx. 145 nF/km
Inductance approx. 0.68 mH/km
Characteristic impedance approx. 80 Ohm
Coupling resistance max. 250 Ohm/km
Minimum bending radius moving 10x cable Ø stationary 5x cable Ø
Radiation resistance up to 80x106 cJ/kg (up to 80 Mrad)
Structure:
Bare copper wire, in accordance with DIN VDE 0295 cl.5, fine-wire, BS 6360 cl.5, IEC 60228 cl.5
Core insulation made of special PVC
Core identification (pair) in accordance with DIN 47100
Cores twisted in pairs
Core pairs twisted in layers Separating
foil
Shielding braid made of tinned copper wires, coverage approx. 85%
Outer jacket made of special PVC
Jacket color blue (RAL 5015) with meter marking
Properties:
Largely oil-resistant, oil/chemical resistance
The materials used in production are silicone and cadmium-free and free from substances that impair paint wetting
Tests:
PVC self-extinguishing and flame-retardant in accordance with DIN VDE 0482-332-1-2, DIN EN 60332-1-2, IEC 60332-1
Use:
For potentially explosive areas as a flexible control cable for intrinsically safe circuits/systems, this paired cable complies with VDE regulation 0165, part 1, section 12. 2. 2. 6, according to which cables and lines in ignition protection type -i- must be specially marked. It is used for secure data transmission. The paired stranding and overall copper shielding offer protection against electrical interference pulses. EMC = Electromagnetic compatibility To optimize the EMC properties, we recommend a large-area, all-round contact on both sides of the copper braid.
Standard lengths: 100 m, 500 m, 1000 m
Subject to technical changes.
Type: 14090
The final cable weight will be determined before invoicing. The calculation is based on the copper content and any additional weight due to drums, pallets, or outer packaging. Prices are subject to this subsequent calculation.
Please note that for cables, that are not in stock and must be produced, the manufacturer may need an order of a minimum length that can be 5-10km depending on cable type!
