Helukabel 14035 HELU OZ-BL-CY 18x0,75qmm special PVC, tubing
|
6,88 EUR |
|||||||||||
|
incl. 1,81 EUR copper surcharge ( 8,19 EUR incl. VAT ) plus delivery charges |
|||||||||||
| Delivery time on requestinfo_outline | |||||||||||
| Lieske Part No.: | 633282 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 14035 | ||||||||||
| UPC/EAN: | 4060892026898 | ||||||||||
| Weight: | 0.12 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Helukabel 14035:
Technical data:
Special PVC hose cable based on DIN VDE 0285-525-2-51 / DIN EN 50525-2-51Temperature range moving -10°C to +80°C fixed -40°C to +80°C
Nominal voltage U0/U 300/500 V
Test voltage 3000 V
Breakdown voltage min. 6000 V
Operating capacitance core/core approx. 140 nF/km core/shield approx. 187 nF/km
Inductance approx. 0.68 mH/km
Coupling resistance max. 250 Ohm/km
Minimum bending radius moving 10x cable Ø not moving 5x cable Ø
Radiation resistance up to 80x106 cJ/kg (up to 80 Mrad)
Construction:
Bare copper wire, in accordance with DIN VDE 0295 class 5, fine-stranded, BS 6360 cl.5, IEC 60228 cl.5
Core insulation made of special PVC
Core identification according to DIN VDE 0293 Black cores with continuous white numbering
Cores stranded in layers with optimal lay lengths Separating
foil
Shielding braid made of tinned copper wires, coverage approx. 85%
Outer jacket made of special PVC
Jacket color: blue (RAL 5015) with meter marking
Properties:
Largely oil-resistant, oil/chemical resistance
The materials used in production are silicone and cadmium-free and free from substances that impair paint wetting
Tests:
PVC self-extinguishing and flame-retardant according to DIN VDE 0482-332-1-2, DIN EN 60332-1-2, IEC 60332-1-2
Notes:
For installation in potentially explosive areas with ignition type -i- for intrinsically safe systems, in accordance with DIN EN 60079-14 Section 16.2.2 (VDE 0165 Part 1)
Computer cable RE-2Y(St)Yv with blue sheath see data and computer cables.
Use:
For potentially explosive areas, flexible control or measuring cable marked as intrinsically safe (blue) (ignition type i) for intrinsically safe systems in measurement and control technology. These systems are not earthed and have a separate circuit. These cables are not suitable for laying underground. The shielding ensures precise data transmission. EMC = Electromagnetic Compatibility To optimize the EMC properties, we recommend contacting the copper braid on both sides and over a large area all around.
Standard lengths: 100 m, 500 m, 1000 m
Subject to technical changes.
Type: OZ-BL-CY 18x0,75qmm
The final cable weight will be determined before invoicing. The calculation is based on the copper content and any additional weight due to drums, pallets, or outer packaging. Prices are subject to this subsequent calculation.
Please note that for cables, that are not in stock and must be produced, the manufacturer may need an order of a minimum length that can be 5-10km depending on cable type!
