Helukabel 13418 HELU MEGAFLEX® 500 5G1.5 Gray UL/CSA control cable halogen-free content_copy

The halogen-free control cable type 13418 is a flexible, high-quality cable in accordance with DIN VDE 0285-525-3-11 and DIN EN 50525-3-11, additionally certified according to UL Style 20939 and UL Std. 758. It is ideally suited for applications in machine and plant engineering, climate technology, storage and handling technology, shipbuilding, as well as in the field of renewable energies such as wind turbine construction. The cable features high mechanical load capacity and flexibility, is resistant to oils, fats, weather influences, UV radiation, hydrolysis, and ozone, and is abrasion- and wear-resistant. The materials used are silicone- and cadmium-free and do not contain any substances that impair paint adhesion, thus enhancing processability and environmental compatibility. The cable is highly flame-retardant and self-extinguishing, in accordance with DIN VDE 0482-332-1-2 and CSA FT1, and meets the requirements for halogen-free properties as well as low smoke density in case of fire. The grey outer sheath (RAL 7001) with meter marking and the black conductors with white digit printing according to DIN VDE 0293 enable easy identification and installation. The Cu stranded conductor complies with DIN VDE 0295 Class 5 (fine-stranded) and ensures high flexibility. The cable is suitable for fixed installation or flexible applications, without repeated movement and without tensile stress. The rated voltage is 300/500 V (UL/CSA 600 V), the test voltage is 3000 V. The temperature range for moving installation is between -30°C and +80°C, and for fixed installation between -40°C and +80°C. The minimum bending radius is 10 times the cable diameter for moving installation and 4 times for fixed installation. Flexibility is confirmed by alternating bend testing according to DIN VDE 0473-396 / DIN EN 50396. The cable is recyclable and thus environmentally friendly.

Technical Data

• Type: 13418
• Category: Halogen-free control cables
• Standards: DIN VDE 0285-525-3-11, DIN EN 50525-3-11, UL Style 20939, UL Std. 758
• Rated voltage: U0/U 300/500 V (UL/CSA 600 V)
• Test voltage: 3000 V
• Temperature range moving: -30°C to +80°C
• Temperature range fixed: -40°C to +80°C
• Minimum bending radius moving: 10x cable Ø
• Minimum bending radius fixed: 4x cable Ø
• Flexibility: Alternating bend test according to DIN VDE 0473-396 / DIN EN 50396
• Construction: Bare Cu stranded conductor, Class 5 (DIN VDE 0295), fine-stranded
• Conductor insulation: Halogen-free special polymer
• Conductor identification: Black with white digit printing (DIN VDE 0293)
• Conductor arrangement: Twisted in layers with optimal lay lengths
• Outer sheath: Halogen-free special polymer, grey (RAL 7001)
• Meter marking: Present
• Properties: Highly flame-retardant, self-extinguishing, oil- and fat-resistant, weather- and UV-resistant, hydrolysis-resistant, abrasion- and wear-resistant, ozone-resistant, recyclable
• Material approvals: Silicone- and cadmium-free, free from paint adhesion interfering substances
• Tests: Fire test DIN VDE 0482-332-3-24, Flame retardancy DIN VDE 0482-332-1-2, Halogen-free DIN VDE 0482-754-1, Smoke density DIN VDE 0482-1034-1+2, Oil resistance DIN VDE 0473-811-404, Hydrolysis resistance DIN EN 61234-1, Ozone resistance DIN VDE 0473-811-403
• Applications: Machine and plant engineering, climate technology, storage and handling technology, shipbuilding, wind turbine construction
• Standard lengths: 100 m, 500 m, 1000 m
• Note: Also available as 0.6/1 kV cable (MEGAFLEX 600) and shielded version (MEGAFLEX 500-C)

Type: 13418
