HELU OZ-500 HMH-C HELUKABEL PVC-PUR-Schl OZ-500 HMH-C 2x2,5mm² Standard length: 100 M
|
265,12 EUR |
|||||||||||
|
incl. 82,50 EUR copper surcharge ( 315,49 EUR incl. VAT ) plus delivery charges |
|||||||||||
| Delivery time on requestinfo_outline | |||||||||||
| Sales unit: 100 meters | |||||||||||
| Lieske Part No.: | 1103658 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | 11744-100 | ||||||||||
| Weight: | 0.12 kg | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Helukabel 11744-100:
Technical data:
halogen-free, flexible control cable, based on DIN VDE 0285-525-2-51 / DIN EN 50525-2-51 and DIN VDE 0285-525-3-11 / DIN EN 50525-3-11Temperature range moving -15°C to +70°C fixed -40°C to +70°C
Nominal voltage U0/U 300/500 V
Test voltage 2000 V
Coupling resistance max. 250 Ohm/km
Minimum bending radius moving 12.5x cable Ø fixed 4x cable Ø
Radiation resistance up to 100x106 cJ/kg (up to 100 Mrad)
Structure:
bare copper wire, according to DIN VDE 0295 cl.5, fine-wire, BS 6360 cl.5, IEC 60228 cl.5
Core insulation made of halogen-free polymer
Core identification according to DIN VDE 0293 Black cores with continuous white numbering
Cores stranded in layers with optimal lay lengths Separating
foil
Shielding braid made of tinned copper wires, coverage approx. 85%
Outer jacket made of halogen-free polymer
Jacket color: gray (RAL 7001) with meter marking
Properties:
The materials used in production are silicone and cadmium-free and free from substances that impair paint wetting
Tests:
Fire test according to DIN VDE 0482-332-3-24, BS 4066 Part 3, DIN EN 60332-3-24, IEC 60332-3-24 (previously DIN VDE 0472 Part 804 test type C)
Self-extinguishing and flame-retardant according to DIN VDE 0482-332-1-2, DIN EN 60332-1-2, IEC 60332-1-2 (corresponds to DIN VDE 0472 Part 804 test type B)
Corrosivity of combustion gases according to DIN VDE 0482-754-2, DIN EN 60754-2, IEC 60754-2 (previously DIN VDE 0482-267-2-2)
Halogen-free according to DIN VDE 0482-754-1, DIN EN 60754-1, IEC 60754-1 (previously DIN VDE 0482-267-2-1) Smoke density
according to DIN VDE 0482 Part 1034-1+2, DIN EN 61034-1+2, IEC 61034-1+2, BS 7622 Part 1+2
Notes:
'Cleanroom qualified\lashunshielded analogue type: JZ-500 HMH
Use:
Used as a measuring, monitoring and control cable on machine tools, conveyor belts, production lines, in plant construction, in air conditioning technology, in steel and steel rolling mills. For fixed installation or flexible use, with occasional, not constantly recurring free movement without forced movement control and without tensile stress, with medium mechanical stress. The cable is suitable for use in dry, damp and wet rooms and on plaster. The high shielding density ensures interference-free transmission of signals and pulses. EMC = Electromagnetic compatibility To optimize the EMC properties, we recommend contacting the copper braid on both sides and over a large area all around.
Standard lengths: 100 m, 500 m, 1000 m
Subject to technical changes.
Type: OZ-500 HMH-C
The item price shown refers to 100 meters Helukabel 11744-100
Questions & answers
What is the delivery time of HELU OZ-500 HMH-C HELUKABEL PVC-PUR-Schl OZ-500 HMH-C 2x2,5mm² Standard length: 100 M?
The article HELU OZ-500 HMH-C HELUKABEL PVC-PUR-Schl OZ-500 HMH-C 2x2,5mm² Standard length: 100 M is currently not in stock und muss auftragsbezogen bestellt werden.
According to our experience the article is ready for dispatch within 8 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Helukabel 11744-100 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you HELU OZ-500 HMH-C HELUKABEL PVC-PUR-Schl OZ-500 HMH-C 2x2,5mm² Standard length: 100 M always at the best possible price. We can give you a discount of 2% on HELU OZ-500 HMH-C HELUKABEL PVC-PUR-Schl OZ-500 HMH-C 2x2,5mm² Standard length: 100 M if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduation prizes with every purchase. If you buy a minimum of 5 meters of HELU OZ-500 HMH-C HELUKABEL PVC-PUR-Schl OZ-500 HMH-C 2x2,5mm² Standard length: 100 M we can offer you a price of 259,64 EUR per piece. The more you buy, the cheaper the article will be.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
How many units does the article contain?
HELU OZ-500 HMH-C HELUKABEL PVC-PUR-Schl OZ-500 HMH-C 2x2,5mm² Standard length: 100 M is offered by us in a sales unit of 100 meters If you need a larger quantity, you can contact us at any time. We will make a special offer for you
