Helukabel 10016 HELU JZ-500 18G0.5qmm gray control cable PVC
|
2,84 EUR |
|
|
incl. 0,64 EUR copper surcharge ( 3,38 EUR incl. VAT ) plus delivery charges |
|
| Delivery time on requestinfo_outline | |
| Lieske Part No.: | 1322977 |
|---|---|
| Mfg Part No: | 10016 |
| UPC/EAN: | 4060892001345 |
| Weight: | 0 kg |
Product information for Helukabel 10016:
Technical data:
Special PVC sheathed cable GN-GE based on DIN VDE 0285-525-2-51 / DIN EN 50525-2-51Temperature range moving -15°C to +80°C fixed -40°C to +80°C
Nominal voltage U0/U 300/500 V
Test voltage 4000 V
Breakdown voltage min. 8000 V
Insulation resistance min. 20 MOhm x km
Minimum bending radius moving 7.5x cable Ø fixed 4x cable Ø
Radiation resistance up to 80x106 cJ/kg (up to 80 Mrad)
Construction:
Bare copper wire, according to DIN VDE 0295 cl.5, fine-wire, BS 6360 cl.5, IEC 60228 cl.5
Core insulation made of special PVC
Core marking according to DIN VDE 0293 black Cores with continuous white numbering
Cores twisted in layers with optimal lay lengths
Outer jacket made of special PVC
Jacket colour: grey (RAL 7001) with meter marking
Properties:
Largely oil-resistant, oil/chemical resistance
conditionally suitable for drag chains, conditionally suitable for torsion
The materials used in production are free from silicone and cadmium and free from substances that impair paint wetting
Tests:
PVC self-extinguishing and flame-retardant in accordance with DIN VDE 0482-332-1-2, DIN EN 60332-1-2, IEC 60332-1-2 (corresponds to DIN VDE 0472 Part 804 test type B)
Notes:
'Cleanroom qualified\lashshielded analogue types: F-CY-JZ, F-CY-OZ (LiY-CY), Y-CY-JB, Y-CY-JZ
Use:
Used for medium mechanical stress for flexible application with free movement without Tensile stress and without forced movement in dry, damp and wet rooms, but not outdoors, as a measuring, monitoring and control cable on machine tools, assembly lines and conveyor belts, production lines, in plant engineering, in air conditioning technology, in steel and steel rolling mills.
Standard lengths: 50 m, 100 m, 500 m, 1000 m.
Technical changes reserved.
Type: JZ-500 18G0,5 QMM
The final cable weight will be determined before invoicing. The calculation is based on the copper content and any additional weight due to drums, pallets, or outer packaging. Prices are subject to this subsequent calculation.
Please note that for cables, that are not in stock and must be produced, the manufacturer may need an order of a minimum length that can be 5-10km depending on cable type!
