Hager KR02SIN feed-in terminal 16 mm and end angle for 10x3 busbar
|
9,31 EUR 9,70 EUR |
|||||||||||
|
( 11,08 EUR incl. VAT ) ≈ £7.80 | ≈ $10.46 plus delivery charges: 53,00 € |
|||||||||||
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |||||||||||
| Datasheet: | file_download Download | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Lieske Part No.: | 893717 | ||||||||||
| Mfg Part No: | KR02SIN | ||||||||||
| UPC/EAN: | 3250610134139 | ||||||||||
| Weight: | 0.0043 kg | ||||||||||
| Type: | KR02SIN | ||||||||||
|
Graduated prices net
|
|||||||||||
Product information for Hager KR02SIN:
| General | |
| Connectable conductor cross section fine-strand without cable end sleeve | 25 mm² |
| Connectable conductor cross section fine-strand with cable end sleeve | 16 mm² |
| Connectable conductor cross section solid-core | 16 mm² |
| Connectable conductor cross section multi-wired | 25 mm² |
| Rated current In | 76 A |
| Rated voltage | 1000 V |
| Type of electrical connection 1 | Plug clamp connection |
| Type of electrical connection 2 | Plug clamp connection |
| Number of potentials | 1 |
| Mounting method | DIN rail (top hat rail)/G-rail TH35/G32 |
| Material insulation body | Thermoplastic |
| Operation temperature | 130 °C |
| Inflammability class of insulation material acc. with UL94 | V0 |
| Basic colour | Blue |
| Depth | 52.9 mm |
| Height | 91.15 mm |
| Width | 12 mm |
| Closing plate required | |
| PE-function | |
| With N-disconnect slide | |
| N function possible | |
Questions & answers
What is the delivery time of Hager KR02SIN feed-in terminal 16 mm and end angle for 10x3 busbar?
The article Hager KR02SIN feed-in terminal 16 mm and end angle for 10x3 busbar is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Hager KR02SIN to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Hager KR02SIN feed-in terminal 16 mm and end angle for 10x3 busbar always at the best possible price. We can give you a discount of 2% on Hager KR02SIN feed-in terminal 16 mm and end angle for 10x3 busbar if you choose payment in advance on ordering.
In addition, you can save money with our attractive graduated prizes with every purchase. If you buy a minimum of 25 pieces of Hager KR02SIN feed-in terminal 16 mm and end angle for 10x3 busbar we can offer you a price of 8,75 EUR per piece. The more you buy, the cheaper the article will be.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
