Gigabyte power supply UD1000GM 1000Watt
|
113,51 EUR |
|
|
( 135,08 EUR incl. VAT ) ≈ £95.01 | ≈ $126.56 plus delivery charges: 55,00 € |
|
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |
| End-Of-Life: | 26. Jul 2026 |
|---|---|
| Lieske Part No.: | 2084933 |
| Mfg Part No: | GP-UD1000GM |
| UPC/EAN: | 4719331552411 |
| Weight: | 2.9 kg |
Product information for Gigabyte GP-UD1000GM:
Das Gigabyte UD1000GM ist ein leistungsstarkes, vollmodulares PC-Netzteil mit 1000 W Gesamtleistung und 80 PLUS Gold-Zertifizierung, das für moderne Desktop-PCs mit leistungsintensiven Komponenten (z. B. Gaming-Grafikkarten und Multi-Core-CPUs) konzipiert ist. Es kombiniert hohen Wirkungsgrad, modulares Kabelmanagement und solide Schutzfunktionen in einem kompakten ATX-Format.
Dieses Netzteil ist ideal für PC-Systeme mit hohem Leistungsbedarf, z. B. Gaming-PCs mit kräftigen Grafikkarten, Multi-Drive-Setups oder Workstations. Die Gold-Effizienz und das vollmodulare Design sorgen für bessere Effizienz, geringere Abwärme und aufgeräumtes Kabelmanagement, was zu stabiler Leistung und besserer Luftzirkulation führt.
| Design | |
| Product colour | Black |
| Fan diameter | 12 cm |
| Number of fans | 1 fan(s) |
| Fan location | Top |
| On/off switch | |
| Logistics data | |
| Harmonized System (HS) code | 84733020 |
| Packaging content | |
| Cables included | CPU, PCIe, Peripheral (Molex), SATA |
| Packaging data | |
| Package type | Box |
| Performance | |
| 80 PLUS certification | 80 PLUS Gold |
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| Bearing technology | HDB |
| Mean time between failures (MTBF) | 100000 h |
| Ports & interfaces | |
| Motherboard power connector | 20+4 pin ATX |
| Motherboard power cable length | 61 cm |
| Number of SATA power connectors | 8 |
| Peripheral (Molex) power connectors (4-pin) | 3 |
| PCI Express power connectors (6+2 pin) | 6 |
| CPU power cable length | 60 cm |
| Floppy drive power connector | 1 |
| Cabling type | Fully-Modular |
| EPS power connector (4+4 pin) | |
| CPU power connector (4+4 pin) | |
| ATX power connector (20+4 pin) | |
| Power | |
| Total power | 1000 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 15 - 6.5 A |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 125 W |
| Combined power (+12V) | 999.6 W |
| Combined power (+5V) | 125 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 25 A |
| Max output current (+12V) | 83.3 A |
| Max output current (+5V) | 25 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 3 A |
| Hold time | 16 ms |
| Efficiency | 90% |
| Power protection features | Over current, Over power, Over voltage, Short circuit, Under voltage |
| Weight & dimensions | |
| Width | 140 mm |
| Depth | 150 mm |
| Height | 86 mm |
Questions & answers
What is the delivery time of Gigabyte power supply UD1000GM 1000Watt?
The article Gigabyte power supply UD1000GM 1000Watt is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Gigabyte GP-UD1000GM to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Gigabyte power supply UD1000GM 1000Watt always at the best possible price. We can give you a discount of 2% on Gigabyte power supply UD1000GM 1000Watt if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
