Gigabyte 6NR282Z90MR-00 Barebone R282-Z90
|
2.731,15 EUR |
|
|
( 3.250,07 EUR incl. VAT ) ≈ £2,285.97 | ≈ $3,045.23 plus delivery charges: 55,00 € |
|
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 1191898 |
| Mfg Part No: | 6NR282Z90MR-00 |
| UPC/EAN: | 4719331191214 |
| Weight: | 0 kg |
| Design | |
| Chassis type | Rack (2U) |
| Product colour | Black |
| Number of fans | 4 fan(s) |
| Fan diameter | 8 cm |
| LED indicators | |
| On/off switch | |
| Reset button | |
| Rack rails | |
| Expansion slots | |
| PCI Express slots version | 4.0 |
| PCI Express x8 slots | 6 |
| PCI Express x16 slots | 3 |
| PCI Express x8 (Gen 3.x) slots | 1 |
| Number of M.2 (M) slots | 1 |
| Features | |
| Integrated BMC with IPMI | |
| Trusted Platform Module (TPM) | |
| Backplanes support | |
| Graphics | |
| On-board graphics card model | Aspeed AST2500 |
| Logistics data | |
| Harmonized System (HS) code | 84714100 |
| Memory | |
| Number of DIMM slots | 32 |
| Supported memory types | DDR4-SDRAM |
| Maximum internal memory | 128 GB |
| Supported RDIMM clock speeds | 2933,3200 MHz |
| Memory channels | Octa-channel |
| Network | |
| Ethernet interface type | Fast Ethernet, Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| LAN controller | Intel® I350-AM2 |
| Ethernet LAN | |
| Operational conditions | |
| Operating temperature (T-T) | 10 - 35 °C |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 8 - 80% |
| Storage relative humidity (H-H) | 20 - 95% |
| Packaging data | |
| Package width | 982 mm |
| Package depth | 588 mm |
| Package height | 268 mm |
| Package weight | 25.5 kg |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| Internal USB 3.2 Gen 1 (3.1 Gen 1) ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| VGA (D-Sub) ports quantity | 1 |
| IPMI LAN (RJ-45) port | |
| Power | |
| Power supply | 1200 W |
| Number of main power supplies | 2 |
| Number of redundant power supplies installed | 2 |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 7 - 12 A |
| 80 PLUS certification | 80 PLUS Platinum |
| Redundant power supply (RPS) support | |
| Processor | |
| Processor socket | Socket SP3 |
| Processor family | AMD |
| Number of processors supported | 2 |
| Compatible processor series | AMD EPYC |
| Built-in processor | |
| Storage | |
| Number of storage drives supported | 14 |
| Number of 2.5" bays | 2 |
| Storage drive sizes supported | 2.5,3.5" |
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | Serial ATA III, Serial Attached SCSI (SAS) |
| Hot-swap HDD bays | |
| Technical details | |
| Compliance certificates | RoHS |
| Weight & dimensions | |
| Width | 438 mm |
| Depth | 730 mm |
| Height | 87 mm |
| Weight | 18 kg |
Questions & answers
What is the delivery time of Gigabyte 6NR282Z90MR-00 Barebone R282-Z90?
The article Gigabyte 6NR282Z90MR-00 Barebone R282-Z90 is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Gigabyte 6NR282Z90MR-00 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Gigabyte 6NR282Z90MR-00 Barebone R282-Z90 always at the best possible price. We can give you a discount of 2% on Gigabyte 6NR282Z90MR-00 Barebone R282-Z90 if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
