Gigabyte 6NH262NO1MR-00 Barebone H262-NO1
|
7.993,49 EUR 7.993,49 EUR |
|
|
( 9.512,25 EUR incl. VAT ) ≈ £6,690.55 | ≈ $8,912.74 plus delivery charges: 55,00 € |
|
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |
| Lieske Part No.: | 1191542 |
|---|---|
| Mfg Part No: | 6NH262NO1MR-00 |
| UPC/EAN: | 4719331601454 |
| Weight: | 0 kg |
| Design | |
| Chassis type | Rack (2U) |
| Product colour | Black, Steel |
| LED indicators | Status |
| Cooling type | Active |
| Number of fans | 8 fan(s) |
| Fan diameter | 8 cm |
| On/off switch | |
| Reset button | |
| Heat sink included | |
| Expansion slots | |
| PCI Express x16 (Gen 4.x) slots | 8 |
| Features | |
| Compatible operating systems | Citrix Hypervisor 8.2.0 or later; Red Hat Enterprise Linux 7.9 or later; Red Hat Enterprise Linux 8.2 or later; Red Hat Enterprise Linux 9.0 or later; SUSE Linux Enterprise Server 12 SP5 or later; SUSE Linux Enterprise Server 15 SP2 or later; Ubuntu 20.04 LTS or later; Ubuntu 22.04 LTS or later; VMware ESXi 6.7 Update3 P03 or later; VMware ESXi 7.0 Update2 or later; VMware ESXi 8.0 or later; Windows Server 2016; Windows Server 2019; Windows Server 2022 |
| Trusted Platform Module (TPM) | |
| Backplanes support | |
| Graphics | |
| On-board graphics card model | Aspeed AST2600 |
| Memory | |
| Number of DIMM slots | 64 |
| Supported memory types | DDR4-SDRAM |
| Maximum RDIMM memory | 128 GB |
| Memory channels | Octa-channel |
| Operational conditions | |
| Operating temperature (T-T) | 10 - 30 °C |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 8 - 80% |
| Storage relative humidity (H-H) | 20 - 95% |
| Packaging data | |
| Packaging content | 1 x H262-NO1; 8 x CPU heatsinks; 1 x 3-Section Rail kit |
| Package width | 1180 mm |
| Package depth | 779 mm |
| Package height | 300 mm |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 8 |
| VGA (D-Sub) ports quantity | 4 |
| Power | |
| Power supply | 2200 W |
| Number of main power supplies | 2 |
| Number of redundant power supplies supported | 2 |
| Number of redundant power supplies installed | 2 |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Input current | 12.6 - 14 A |
| 80 PLUS certification | 80 PLUS Platinum |
| Redundant power supply (RPS) support | |
| Processor | |
| Motherboard chipset | Intel C621A |
| Processor socket | LGA 4189 |
| Number of processors supported | 8 |
| Compatible processor series | Intel® Xeon® |
| Built-in processor | |
| Storage | |
| Number of storage drives supported | 24 |
| Number of 2.5" bays | 24 |
| Storage drive sizes supported | 2.5" |
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | PCI Express 4.0, Serial ATA, Serial Attached SCSI (SAS) |
| RAID levels | 0, 1, 5, 10 |
| SSD form factor | 2.5" |
| Hot-swap HDD bays | |
| Weight & dimensions | |
| Width | 440 mm |
| Depth | 840 mm |
| Height | 87.5 mm |
| Weight | 27.8 kg |
Questions & answers
What is the delivery time of Gigabyte 6NH262NO1MR-00 Barebone H262-NO1?
The article Gigabyte 6NH262NO1MR-00 Barebone H262-NO1 is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Gigabyte 6NH262NO1MR-00 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Gigabyte 6NH262NO1MR-00 Barebone H262-NO1 always at the best possible price. We can give you a discount of 2% on Gigabyte 6NH262NO1MR-00 Barebone H262-NO1 if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
