Gigabyte 6NH233Z80DR000AAN1 Barebone H233-Z80-AAN1
|
6.899,88 EUR 6.899,88 EUR |
|
|
( 8.210,86 EUR incl. VAT ) ≈ £5,775.20 | ≈ $7,693.37 plus delivery charges: 55,00 € |
|
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 1191522 |
| Mfg Part No: | 6NH233Z80DR000AAN1 |
| UPC/EAN: | 4719331856731 |
| Weight: | 0 kg |
| Design | |
| Chassis type | Rack (2U) |
| Product colour | Black, Steel |
| LED indicators | Status |
| Cooling type | Active |
| Number of fans | 4 fan(s) |
| Fan diameter | 8 cm |
| On/off switch | |
| Reset button | |
| Heat sink included | |
| Expansion slots | |
| PCI Express x16 (Gen 5.x) slots | 6 |
| Features | |
| Trusted Platform Module (TPM) | |
| Backplanes support | |
| Graphics | |
| On-board graphics card model | Aspeed AST2600 |
| Memory | |
| Number of DIMM slots | 48 |
| Supported memory types | DDR5-SDRAM |
| Memory channels | Dodeca-channel |
| Network | |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| LAN controller | Intel® I350-AM2 |
| Ethernet LAN | |
| Operational conditions | |
| Operating temperature (T-T) | 10 - 30 °C |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 8 - 80% |
| Storage relative humidity (H-H) | 20 - 95% |
| Packaging data | |
| Packaging content | 1 x H233-Z80-AAN1; 4 x CPU heatsinks; 1 x Mini-DP to D-Sub cable; 4 x GPU power cables (CPU 8pin, 400mm); 1 x 3-Section Rail kit |
| Package width | 1184 mm |
| Package depth | 706 mm |
| Package height | 394 mm |
| Package weight | 64.1 kg |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| Ethernet LAN (RJ-45) ports | 4 |
| Mini DisplayPorts quantity | 2 |
| Power | |
| Power supply | 2600 W |
| Number of main power supplies | 2 |
| Number of redundant power supplies supported | 2 |
| Number of redundant power supplies installed | 2 |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Input current | 15 A |
| 80 PLUS certification | 80 PLUS Titanium |
| Redundant power supply (RPS) support | |
| Processor | |
| Motherboard chipset | AMD SoC |
| Processor socket | Socket SP5 |
| Number of processors supported | 4 |
| Compatible processor series | AMD EPYC 9004 |
| Built-in processor | |
| Storage | |
| Number of storage drives supported | 4 |
| Number of 2.5" bays | 4 |
| Storage drive sizes supported | 2.5" |
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | PCI Express 4.0 |
| SSD form factor | 2.5" |
| Hot-swap HDD bays | |
| Weight & dimensions | |
| Width | 440 mm |
| Depth | 877 mm |
| Height | 87.5 mm |
| Weight | 59.1 kg |
Questions & answers
What is the delivery time of Gigabyte 6NH233Z80DR000AAN1 Barebone H233-Z80-AAN1?
The article Gigabyte 6NH233Z80DR000AAN1 Barebone H233-Z80-AAN1 is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Gigabyte 6NH233Z80DR000AAN1 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Gigabyte 6NH233Z80DR000AAN1 Barebone H233-Z80-AAN1 always at the best possible price. We can give you a discount of 2% on Gigabyte 6NH233Z80DR000AAN1 Barebone H233-Z80-AAN1 if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
