Gigabyte 6NE133X10MR000ABG1
E133-X10-AAG1 1U Xeon 6300-Series/E-2400 2x800W
|
-19% 1.086,56 EUR 1.346,80 EUR |
|
|
( 1.293,01 EUR incl. VAT ) ≈ £914.88 | ≈ $1,220.21 plus delivery charges: 148,00 € |
|
| Made to order · Expected to be available from 01.01.2199info_outline | |
| Datasheet: | file_download Download |
|---|---|
| Lieske Part No.: | 2129575 |
| Mfg Part No: | 6NE133X10MR000ABG1 |
| Weight: | 13.3 kg |
| Design | |
| Chassis type | Rack (1U) |
| Product colour | Black, Steel |
| LED indicators | LAN, HDD, SSD, Status |
| Cooling type | Active |
| Number of fans | 4 fan(s) |
| Fan diameter | 4 cm |
| On/off switch | |
| Reset button | |
| Heat sink included | |
| Expansion slots | |
| PCI Express x4 slots | 1 |
| PCI Express x16 (Gen 5.x) slots | 1 |
| Number of M.2 (M) slots | 1 |
| Graphics | |
| On-board graphics card model | Aspeed AST2600 |
| Memory | |
| Number of DIMM slots | 4 |
| Supported memory types | DDR5-SDRAM |
| Memory channels | Dual-channel |
| ECC | |
| Network | |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| LAN controller | Intel® I210-AT |
| Ethernet LAN | |
| Operational conditions | |
| Operating temperature (T-T) | 10 - 35 °C |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 8 - 80% |
| Storage relative humidity (H-H) | 20 - 95% |
| Packaging data | |
| Packaging content | 1 x E133-X10-AAG1;1 x CPU heatsink;1 x Mini-DP to D-Sub cable |
| Package width | 787 mm |
| Package depth | 594 mm |
| Package height | 226 mm |
| Package weight | 14 kg |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| Ethernet LAN (RJ-45) ports | 2 |
| Mini DisplayPorts quantity | 1 |
| Power | |
| Power supply | 800 W |
| Number of main power supplies | 2 |
| Number of redundant power supplies supported | 2 |
| Number of redundant power supplies installed | 2 |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Input current | 5 - 10 A |
| 80 PLUS certification | 80 PLUS Titanium |
| Redundant power supply (RPS) support | |
| Processor | |
| Motherboard chipset | Intel C262 |
| Processor socket | LGA 1700 |
| Number of processors supported | 1 |
| Compatible processor series | Intel Xeon E, Intel Xeon 6300 |
| Intel Xeon series | E-2400, 6300 |
| Built-in processor | |
| Storage | |
| Number of storage drives supported | 3 |
| Number of 2.5" bays | 2 |
| Storage drive sizes supported | 2.5,M.2 |
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | Serial ATA |
| RAID levels | 0, 1 |
| SSD form factor | M.2 |
| Hot-swap HDD bays | |
| Weight & dimensions | |
| Width | 438 mm |
| Depth | 520 mm |
| Height | 43.5 mm |
| Weight | 12.1 kg |
Questions & answers
What is the delivery time of Gigabyte 6NE133X10MR000ABG1 E133-X10-AAG1 1U Xeon 6300-Series/E-2400 2x800W?
The article Gigabyte 6NE133X10MR000ABG1 E133-X10-AAG1 1U Xeon 6300-Series/E-2400 2x800W is currently not in stock and must be ordered on a per-order basis.
According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of Gigabyte 6NE133X10MR000ABG1 to our sales team for an exact delivery time.
How can I buy the item at a lower price?
We offer you Gigabyte 6NE133X10MR000ABG1 E133-X10-AAG1 1U Xeon 6300-Series/E-2400 2x800W always at the best possible price. We can give you a discount of 2% on Gigabyte 6NE133X10MR000ABG1 E133-X10-AAG1 1U Xeon 6300-Series/E-2400 2x800W if you choose payment in advance on ordering.
We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
