Fujitsu ScanSnap SV600 Overhead Scanner - 1200 dpi Optical - USB
|
774,67 EUR |
|||||||||||
|
( 921,86 EUR incl. VAT ) ≈ £656.92 | ≈ $868.41 plus delivery charges: 83,00 € |
|||||||||||
| Made to order · Delivery time approx. 20 workdaysinfo_outline | |||||||||||
| Lieske Part No.: | 463239 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Mfg Part No: | PA03641-B001-VG | ||||||||||
| UPC/EAN: | 4939761305412 | ||||||||||
| Weight: | 5.11 kg | ||||||||||
| Type: | ScanSnap SV600 Vorführgerät | ||||||||||
|
Graduated prices net
|
|||||||||||
Further Document Scanner from FujitsuFurther products in category Document Scanner
All products of Fujitsu
Product information for Fujitsu PA03641-B001-VG:
The Fujitsu ScanSnap SV600 demonstration unit is a contactless overhead scanner designed specifically for digitizing bound documents, books, newspapers, magazines, and sensitive materials such as pencil writing or photos. It operates without physical contact with the document, thus preventing damage. The device is designed for use in offices and work environments where fast and secure digitization of flat and bound documents is required. It features a compact design with a footprint of 210 mm width and 156 mm depth, making it easy to place on desks.
Applications
This scanner is particularly suitable for digitizing documents that cannot or are difficult to unbind, such as books, bound reports, historical documents, or maps. It can also scan business cards, postcards, and documents in A3 format. The maximum scan size is 432 x 300 mm, with a maximum paper thickness of up to 30 mm supported. The scanning function is not limited to single-sided documents but also enables scanning of flat, multi-page materials in a single operation.
Functions and Features in Detail
The ScanSnap SV600 operates with a color CCD sensor and a white LED light source (2x), ensuring even and interference-free illumination. The optical scan resolution is up to 285 DPI horizontally and up to 283 DPI vertically, with a minimum vertical resolution of 152 DPI. The scan time for an A3-sized area is under 3 seconds. The device features automatic color mode detection, switching between grayscale and monochrome mode depending on the document. Additional features include automatic page-turn detection, time-based scan mode, and automatic correction of skew and page rotation. An integrated tool allows removal of fingers from the image to ensure a clean presentation.
Technology Explained Simply
The VI-Technology" (Visual Intelligence) ensures that image quality inconsistencies are minimized, even if the document is not placed exactly on the scan surface. This is achieved through a lens with high depth of field, a CCD linear image sensor, and an LED light source with high directionality. The combination of these components enables a uniformly sharp image, even with slight variations in distance. The "Book Image Correction function corrects distortions and curvatures in bound documents, ensuring scanned pages appear flat and readable.
Compatibility and Accessories
The scanner is compatible with USB 2.0 and USB 1.1 and can be connected to PCs and Macs. Supported operating systems include Windows 7 to 10 (various editions) and Mac OS X 10.7 to 10.12. The package includes the AC power supply and software Nuance Power PDF (for Windows) as well as Nuance Power PDF Converter (for Mac). For Windows users, the application Rack2-Filer Smart is additionally available, offering an intuitive user interface with bookshelf and binder views. This enables direct scanning into binders, moving binders, attaching images, creating dividers, marking pages, and using OCR functions for keyword and phrase search.
Installation and Setup
Installation is done via the included software. The scanner connects to the computer via USB and is automatically recognized. Operation is performed using a one-touch scan mode, allowing the user to start the scanning process with a single button press. The software supports automatic detection of multiple documents in a single scan and performs automatic cropping. The scanning function is uninterrupted, as page-turn detection and time-based scan mode automatically continue the scanning process.
dOperational Advantages
The ScanSnap SV600 offers fast and reliable digitization of documents without causing physical damage. Automated functions such as skew correction, page rotation, and automatic cropping reduce post-processing time. The integrated software enables structured organization of scanned files, making document search and management more efficient. Power consumption values are 20 W in standard operation, 2.6 W in standby, and 0.4 W when turned off. The device is certified with the ENERGY STAR label, indicating energy-efficient use. The operating temperature is 5 to 35 °C, and the relative humidity during operation is 20 to 80 %.
Applications
This scanner is particularly suitable for digitizing documents that cannot or are difficult to unbind, such as books, bound reports, historical documents, or maps. It can also scan business cards, postcards, and documents in A3 format. The maximum scan size is 432 x 300 mm, with a maximum paper thickness of up to 30 mm supported. The scanning function is not limited to single-sided documents but also enables scanning of flat, multi-page materials in a single operation.
Functions and Features in Detail
The ScanSnap SV600 operates with a color CCD sensor and a white LED light source (2x), ensuring even and interference-free illumination. The optical scan resolution is up to 285 DPI horizontally and up to 283 DPI vertically, with a minimum vertical resolution of 152 DPI. The scan time for an A3-sized area is under 3 seconds. The device features automatic color mode detection, switching between grayscale and monochrome mode depending on the document. Additional features include automatic page-turn detection, time-based scan mode, and automatic correction of skew and page rotation. An integrated tool allows removal of fingers from the image to ensure a clean presentation.
Technology Explained Simply
The VI-Technology" (Visual Intelligence) ensures that image quality inconsistencies are minimized, even if the document is not placed exactly on the scan surface. This is achieved through a lens with high depth of field, a CCD linear image sensor, and an LED light source with high directionality. The combination of these components enables a uniformly sharp image, even with slight variations in distance. The "Book Image Correction function corrects distortions and curvatures in bound documents, ensuring scanned pages appear flat and readable.
Compatibility and Accessories
The scanner is compatible with USB 2.0 and USB 1.1 and can be connected to PCs and Macs. Supported operating systems include Windows 7 to 10 (various editions) and Mac OS X 10.7 to 10.12. The package includes the AC power supply and software Nuance Power PDF (for Windows) as well as Nuance Power PDF Converter (for Mac). For Windows users, the application Rack2-Filer Smart is additionally available, offering an intuitive user interface with bookshelf and binder views. This enables direct scanning into binders, moving binders, attaching images, creating dividers, marking pages, and using OCR functions for keyword and phrase search.
Installation and Setup
Installation is done via the included software. The scanner connects to the computer via USB and is automatically recognized. Operation is performed using a one-touch scan mode, allowing the user to start the scanning process with a single button press. The software supports automatic detection of multiple documents in a single scan and performs automatic cropping. The scanning function is uninterrupted, as page-turn detection and time-based scan mode automatically continue the scanning process.
dOperational Advantages
The ScanSnap SV600 offers fast and reliable digitization of documents without causing physical damage. Automated functions such as skew correction, page rotation, and automatic cropping reduce post-processing time. The integrated software enables structured organization of scanned files, making document search and management more efficient. Power consumption values are 20 W in standard operation, 2.6 W in standby, and 0.4 W when turned off. The device is certified with the ENERGY STAR label, indicating energy-efficient use. The operating temperature is 5 to 35 °C, and the relative humidity during operation is 20 to 80 %.
| Certificates | |
| Green (Eco) compliant | |
| Design | |
| Scanner type | Overhead scanner |
| Product colour | Black, White |
| Built-in display | |
| Logistics data | |
| Country of origin | China |
| Pallet gross length | 101.6 cm |
| Pallet gross width | 121.9 cm |
| Harmonized System (HS) code | 8471607000 |
| Paper packaging weight | 2.4 kg |
| Metal packaging weight | 0 g |
| Wood packaging weight | 0 g |
| Plastic packaging weight | 15 g |
| Products per pallet (air) | 24 pc(s) |
| Products per pallet (sea) | 40 pc(s) |
| Pallet height (sea) | 197.5 cm |
| Pallet height (air) | 124.5 cm |
| Cardboard packaging weight | 1.2 kg |
| Foil packaging weight | 15 g |
| Polystyrene (EPS/EPP) packaging weight | 200 g |
| Glass packaging weight | 0 g |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 35 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Other features | |
| Scan time | 3 s |
| Minimum scan size | 25.4 x 25.4 mm |
| Media thickness | 30 mm |
| Vertical optical scanning resolution (min) | 152 DPI |
| Vertical optical scanning resolution (max) | 283 DPI |
| Horizontal optical scanning resolution (max) | 285 DPI |
| Horizontal optical scanning resolution (min) | 218 DPI |
| Vertical scanning magnification | ±1.5%% |
| Compliance certificates | RoHS |
| Automatic colour mode detection | |
| Packaging content | |
| Cables included | AC |
| Bundled software | Nuance Power PDF (Win) Nuance Power PDF Converter (Mac) |
| AC adapter included | |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Package width | 301 mm |
| Package depth | 500 mm |
| Package height | 365 mm |
| Package weight | 6.5 kg |
| Paper handling | |
| Scanning media types supported | Business Card, Post Card(JPN) |
| Maximum ISO A-series paper size | A3 |
| ISO A-series sizes (A0...A9) | A3, A4, A5, A6 |
| ISO B-series sizes (B0...B9) | B4, B5, B6 |
| Letter | |
| Legal | |
| Performance | |
| Sensor type | CCD |
| Light source | White LED (2x) |
| Ports & interfaces | |
| USB version | 2.0 |
| Socket connector type | C7 |
| Standard interfaces | USB 1.1, USB 2.0 |
| USB port | |
| Power | |
| Power supply type | AC |
| Power consumption (typical) | 20 W |
| Power consumption (standby) | 2.6 W |
| Power consumption (off) | 0.4 W |
| AC input frequency | 50 - 60 Hz |
| Input voltage | 100-240 V |
| Scanning | |
| Maximum scan size | 432 x 300 mm |
| Optical scanning resolution | 285 x 218 DPI |
| Black/white scanning colour modes | Grayscale, Monochrome |
| Colour scanning | |
| Duplex scanning | |
| Film scanning | |
| Sustainability | |
| Sustainability certificates | ENERGY STAR |
| System requirements | |
| Windows operating systems supported | Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 |
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Weight & dimensions | |
| Width | 210 mm |
| Depth | 156 mm |
| Height | 383 mm |
| Weight | 3 kg |
