FRITZ! GmbH 20002965 AVM FRITZ!Box 6690 Cable content_copy

High-end home network with 4x4 Wi-Fi 6The FRITZ!Box 6690 Cable with innovative Wi-Fi 6 (WLAN AX) brings ultra-fast WLAN to the cable connection. The new Wi-Fi 6 (WLAN AX) standard is faster and significantly more efficient: the FRITZ!Box 6690 Cable can effortlessly handle multiple parallel applications such as 4K streams, video conferences and cloud applications. The integrated DOCSIS 3.1 cable modem for ultra-fast gigabit speeds is suitable for all cable connections. A 2.5 Gigabit LAN connection, USB 3.0 and the DECT base for cordless telephony and smart home applications complete the versatile communications offering.

Highlights

• Router with integrated cable modem for all cable connections
• Support for DOCSIS 3.1 with 2x2 OFDMA channel bundling and DOCSIS 3.0 with 32x8 channel bundling
• Secure Internet use through preset firewall
• Innovative dual-band 4x4 Wi-Fi 6 (WLAN AX) designed for a Sophisticated home network with a variety of WLAN devices
• Maximum range and ultra-fast transmissions at 4,800 MBit/s (5 GHz) and 1,200 MBit/s (2.4 GHz)
• Mesh master function: FRITZ!Box contains distributed WLAN access points (e.g. FRITZ!Repeater) into a dynamic, intelligent WLAN network
• Secure WLAN encryption according to the WPA3/2 standard, individual password already activated at the factory
• VoIP telephone system with a wide range of convenient functions for analogue, DECT and IP Telephones
• Basis for up to 6 cordless telephones (e.g. all FRITZ!Fon models)
• Up to 5 integrated answering machines including voice-to-mail
• Management of telephone books, online telephone books can also be integrated, e.g. B. Google
• Smart home center for light, heat and electricity with FRITZ!DECT products
• Simple, German-language user interface for all settings
• Provision of music, films and images via integrated media server, e.g. B. on the Smart TV
• Integrated TV tuner for streaming the television signal in the home network
• Parental controls with versatile filters, e.g. E.g. time-limited Internet access, blocking of websites and file sharing platforms
• Always new functions through regular updates, always up to date through optional auto-update
• Energy savings through time-controlled WLAN shutdown and power adjustment of the LAN (green mode)

Product type

• Stationary router
• ear category (ElektroG): relevant, Category 6: small IT and telecommunications devices, small IT and telecommunications devices B2C

Specifications

• Area of application: Indoor
• Mode type: Cable

Shipping

• WEEE: 86990390 > Connections
• Connection: USB
• USB standard: USB 3.0 (USB 3.2 Gen 1)
• Total number of copper ports: 4
• Number of analog interfaces: 2

Functions

• DHCP server
• Hotspot
• VPN
• UTM functionality: network firewall, VPN support, translation of network addresses (NAT)
• telephony functionality: integrated
• number of DECT devices: 6
• DECT-ULE
• media server
• print server
• fax server
• parental control

power supply

• power supply: external

data transmission

• WLAN
• WLAN standard: IEEE 802.11b - WiFi 1, IEEE 802.11a - WiFi 2, IEEE 802.11g - WiFi 3, IEEE 802.11n - WiFi 4, IEEE 802.11ac - WiFi 5, IEEE 802.11ax - WiFi 6
• Security standard: WPS , WPA2, WPA3

Basic features

• Color: White, Red
• Height: 209 mm
• Length/Depth: 273 mm
• Width: 85 mm
• Weight: 1034 g

Scope of delivery

• FRITZ!Box 6690 Cable
• Power supply
• 1.5 meter coaxial cable
• 1.5 meter LAN cable
• RJ12/TAE adapter
• Installation instructions
