Fränkische Rohrwerke 20210040 Stapa threaded pipe M40 3 m with threaded coupling black

Your rating:
Average rating
product review for Fränkische Rohrwerke 20210040 Stapa threaded pipe M40 3 m with threaded coupling black
( 4.6 / 5 ) 58 ratings
Fränkische Rohrwerke 20210040
This image may differ from the desired article.
Fränkische Rohrwerke 20210040Fränkische Rohrwerke 20210040Fränkische Rohrwerke 20210040Fränkische Rohrwerke 20210040
120,07 EUR 125,13 EUR
( 142,88 EUR incl. VAT )
≈ £100.50  |  ≈ $131.96
plus delivery charges: 55,00 €
Delivery time from supplier's stock (ca.) 3 workdaysinfo_outline
Sales unit: 3 meters
In Stock: >25 meters
1x Fränkische Rohrwerke 20210040 Stapa threaded pipe M40 3 m with threaded coupling black
Datasheet:file_download Download
Lieske Part No.:196423
Mfg Part No: 20210040
UPC/EAN: 4013960165470
Weight:4.44 kg
Type:Staro Gewinde-ES 40 schwarz lackiert
Graduated prices net
From piecesPrice per meters
5106,56 EUR
1093,05 EUR
1579,55 EUR
2066,04 EUR

Product information for Fränkische Rohrwerke 20210040:

The Fränkische Staro threaded-ES 40 black lacquered is a rigid steel pipe made of rolled mild steel, designed for installations with high mechanical requirements. The pipe is supplied in bar lengths of 3 metres and features a baked-on lacquer coating in deep black, corresponding to RAL9005. It is threaded on both ends, with a screwed-on coupling (SM-E) installed at one end. The construction is designed for fixed connections and is particularly suitable for applications requiring high pressure resistance and temperature resistance.

Applications
This product is suitable for a wide range of installation situations, including mounting in concrete, in screed, under plaster, on plaster, in hollow walls, and on wood. It can also be used in hot asphalt and bitumen underfloor installations. Installation in soil is not intended, and outdoor installation is not recommended. The application is particularly common in machine and plant construction as well as in prefabricated construction, where high mechanical load capacity is required.

Functions and Equipment in Detail
The Staro threaded-ES 40 features very high pressure resistance, corresponding to class 5 according to EN 61386-1, with a minimum value of 4000 N/5 cm. The surface is lacquered, providing medium corrosion protection both internally and externally. The temperature resistance ranges from -45 °C to +250 °C, enabling use in various environments. The pipe is not flame-propagating and thus contributes to fire safety requirements.

Technology Explained Simply
The pipe is made of steel (rolled mild steel) and offers high mechanical stability. The baked-on lacquer ensures a uniform, durable surface coating that slows down corrosion. The double-threaded design enables secure connections with other pipe parts or fittings. The screwed-on coupling (SM-E) at one end facilitates installation and ensures a firm connection. The classification 55561 according to VDE 0605 and DIN EN 61386-21 confirms suitability for systems with functional integrity (E30/E60/E90), meaning the cables should remain functional even under fire exposure.

Compatibility and Accessories
Various accessories are compatible with this pipe, enabling flexible installation. These include the Fränkische E-Ku-E 40 plastic end cap in grey or black, which is UV-resistant, and the Fränkische SB-E 40 lacquered steel pipe threaded elbow. These components allow adaptation to different installation geometries and support secure end and bending connections.

Installation and Mounting
The pipe can be installed either recessed or surface-mounted. Installation is possible in concrete, screed, hollow walls, on wood, and in hot asphalt. The installation does not require special tools, as the threaded connections are standardised. Installation in soil is not intended, and outdoor installation is not recommended. The minimum length per delivery is 15 metres, with the base unit being the metre.

Operational Advantages
The high pressure resistance and temperature resistance ensure long service life and reliability under load. The corrosion protection provided by the baked-on lacquer reduces maintenance and extends service life. Suitability for functional integrity (E30/E60/E90) makes the pipe particularly suitable for critical systems where power supply must be maintained even during a fire. Its use in machine and plant construction as well as in prefabricated construction demonstrates the product’s versatility.

The item price shown refers to 3 meters Fränkische Rohrwerke 20210040
Delivery form
Minimum quantity15
Pallet content600
Base unit quantityMetre
Technical data
MaterialSteel
Material qualitySteel (mild steel rolled)
Surface protectionLacquered
Quality of surface coatingOther
ModelRigid
Connection 1Inner thread metric
Connection 2Outer thread metric
ColourBlack
Pressure resistance class per EN 61386-1very heavy (Class 5, 4000 N)
Inner diameter36 mm
Outer diameter40 mm
Surface polishedNo
Surface brushedNo
Flush-mounted installationJa
Surface mountingJa
Suitable for concrete installationJa
Machine and plant installationJa
Suitable for subsurface installation (bitumen, hot asphalt)Ja
Suitable for subsurface installation (screed))Ja
Outdoor installationNo
Installation on woodJa
Suitable for hollow wall installationJa
Suitable for underground installationNo


Please note...
This article has over-size and needs to be seperately taken care of. This is why we want to inform you, that the calculation of the delivery charges in the shopping cart will disregard this aspect. Though, there will be corresponding surcharges after you send us your order.
Product data sheet
Datasheet for Fränkische Rohrwerke 20210040, EAN: 4013960165470
