Eizo DuraVision IP video decoder box DX0212-IP black content_copy

The DuraVision DX0212-IP is an ideal solution for video walls and multi-screen security environments. It enables powerful decoding and flexible video management and features a compact design. The decoder box solution can be connected to an IP camera or switch and streams video content directly to a connected monitor. No computer, software or other hardware is required to operate the monitor, making installation much easier and saving time and effort. In addition, sources of error resulting from a traditional configuration are eliminated, as the technical effort required to manage sensitive visual data is greatly reduced. *Connection of IP surveillance cameras and video streaming without a PC *Support 4K UHD and multiple Full HD streams *Powerful decoder technology for up to 16 streams (64 planned for the end of 2019) *Easy change of settings and reactions to events via the web interface and API *Live data protection *Camera protocol support: ONVIF (Panasonic, Axis VAPIX planned for late 2019) *RTSP control support *HDMI output up to 4K UHD at 60 Hz (support second HDMI output for end of 2019)

Features
Product colour	Black
Certification	CB, CE, UKCA, cTUVus, FCC-A, CAN ICES-3 (A), VCCI-A, RCM, RoHS, WEEE, BIS, India RoHS
Network
Ethernet LAN data rates	100,1000 Mbit/s
Cabling technology	10/100/1000BaseE-T(X)
Networking standards	IEEE 802.3at
Supported network protocols	DHCP, DNS, HTTP, HTTPS, LDAP, LDAPS, NTP, RTP, RTSP, SNMP, SRT, SRTP, IEEE802.1X
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80%
Packaging content
Cables included	HDMI
Manual
Performance
Channels quantity	48 channels
Maximum video resolution	3840 x 2160 pixels
Maximum frame rate	60 fps
Video formats supported	H.264, H.265, MPEG, MPEG2
PTZ control
Ports & interfaces
Number of HDMI outputs	2
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	1
Power
AC adapter power	21.5 W
Power consumption (max)	25.5 W
Power over Ethernet (PoE)
Weight & dimensions
Width	165 mm
Depth	130 mm
Height	44.2 mm
Weight	770 g

---
