Eaton 216405 M22-XW plunger bridge

Your rating:
Average rating
product review for Eaton 216405 M22-XW plunger bridge
( 4.4 / 5 ) 7 ratings
Eaton 216405
This image may differ from the desired article.
Eaton 216405Eaton 216405
8,74 EUR 9,11 EUR
( 10,40 EUR incl. VAT )
≈ £7.32  |  ≈ $9.61
plus delivery charges: 55,00 €
Delivery time from supplier's stock (ca.) 3 workdaysinfo_outline
Sales unit: 10 pieces
In Stock: >5 pieces
1x Eaton 216405 M22-XW plunger bridge
Lieske Part No.:362512
Mfg Part No: 216405
UPC/EAN: 4015082164058
Weight:0.123 kg
Type:M22-XW
Graduated prices net
From piecesPrice per pieces
258,48 EUR
508,22 EUR
1007,95 EUR
2507,69 EUR

Product information for Eaton 216405:

The M22-XW plunger bridge from Eaton, manufacturer's number 216405, is a specific accessory for industrial switching devices. It is used to actuate the central contact element in the non-illuminated actuator of the M22-W...3 selector switch, which has three positions. This component is used in electrical and automation technology to precisely shape the function of switching operations in control and regulation circuits. The bridge enables the mechanical connection between the plungers of the switch positions, thereby activating the electrical connection of the central contact element without requiring additional switching contacts.

Plunger bridge is the central term for this product, which functions as a mechanical accessory. It is used in switching installations where a selector switch with three positions is employed and the middle position must be controlled via a separate electrical connection. The bridge ensures that the switch mechanism assumes the corresponding contact position when the operator selects the middle position. The bridge is black in colour, which integrates it visually into the standard design of switching devices.

Selector switch with three positions is the switch type for which this bridge was developed. The M22-W...3 series from Eaton is a standard in industrial control technology, particularly in systems requiring manual intervention or state changes. The M22-XW plunger bridge is specifically designed for non-illuminated versions of the actuator, where no additional illumination of the positions is provided. The bridge is directly installed into the switch and connects the plungers of the positions, so that the electrical connection of the central contact element is activated when the switch is moved to the middle position.

Technology explained clearly: The plunger bridge operates mechanically. It consists of a solid, black-lacquered component that is inserted into the switch. When the operator moves the switch to the middle position, the bridge establishes the mechanical contact with the central contact element. This triggers the electrical connection without requiring additional switching contacts or relays. The bridge is thus a simple but efficient element for extending the functionality of an existing selector switch.

Compatibility and accessories: The M22-XW plunger bridge is exclusively intended for use with the Eaton M22-W...3 selector switch. It is not suitable for other switch models or other manufacturers. Compatibility is limited to the non-illuminated version of the actuator.

Installation and mounting: Mounting is done by inserting the bridge into the switch mechanism. The bridge is inserted into the designated position in the switch and mechanically locks in place. No additional tools or mounting aids are required. Installation takes place directly in the switch housing, ensuring that the bridge is positioned correctly to activate the middle contact position. The bridge is not intended for use in illuminated switches, as the mechanical design is specifically tailored for the non-illuminated variant.

Operational advantages: Using the M22-XW plunger bridge enables precise and reliable control of the central contact element without additional electrical components. This reduces circuit complexity and minimizes the number of required connections. The mechanical reliability of the bridge ensures stable operation even with frequent use. The black lacquered surface matches the standard appearance of switches, preserving the aesthetics of the control interface.

Applications: The plunger bridge is used in industrial control systems, particularly in systems requiring manual state changes, such as in manufacturing automation, building automation, or machine control. It is suitable for applications where the middle position of a selector switch is intended to trigger a specific function without requiring additional switching contacts or relays. The bridge is part of a modular system designed to match the standard components of Eaton's M22 series.

Functions and equipment in detail: The bridge features a solid mechanical construction designed for connecting the plungers in the middle position. The black colour is standard and corresponds to the usual design of switch accessories. The bridge is not illuminated and is not intended for use in illuminated switches. The operation is based solely on the mechanical connection between the plungers and the contact element. There are no additional electrical or optical functions.

Manufacturer and type: The product is manufactured by Eaton, a provider of electrical components and control systems. The M22-XW type is specifically designed for the M22 switch series and serves as a mechanical accessory to extend switching functions. Manufacturer's number 216405 uniquely identifies the product within the manufacturer's range.

The item price shown refers to 10 pieces Eaton 216405
General
ColourBlack
Functionactuation of the central contact element
Compatibilityselector switch M22-W...3, non-illuminated
ManufacturerEaton
