DIGITUS DN-82021-1 Media converter Fast Ethernet RJ45/SC Singlemode

Your rating:
Average rating
product review for DIGITUS DN-82021-1 Media converter Fast Ethernet RJ45/SC Singlemode
( 4.7 / 5 ) 3 ratings
DIGITUS DN-82021-1
This image may differ from the desired article.
DIGITUS DN-82021-1DIGITUS DN-82021-1DIGITUS DN-82021-1DIGITUS DN-82021-1DIGITUS DN-82021-1DIGITUS DN-82021-1
42,43 EUR
( 50,49 EUR incl. VAT )
≈ £35.51  |  ≈ $46.63
plus delivery charges: 55,00 €
Delivery time from supplier's stock (ca.) 7 workdaysinfo_outline
In Stock: >100 pieces
1x DIGITUS DN-82021-1 Media converter Fast Ethernet RJ45/SC Singlemode
Datasheet:file_download Download
Lieske Part No.:453997
Mfg Part No: DN-82021-1
UPC/EAN: 4016032293101
Weight:0.45 kg
Type:DN-82021-1
Graduated prices net
From piecesPrice per pieces
1040,52 EUR
2538,61 EUR
5036,70 EUR
7534,79 EUR

Product information for DIGITUS DN-82021-1:

The DIGITUS media converter DN-82021-1 is a Fast Ethernet converter that transforms wired network signals via RJ45 connectors into fiber optic signals via SC connectors. It serves as a bridge between copper and fiber optic infrastructures, enabling existing networks to migrate to fiber optic without complete reconfiguration. The converter solution allows data transmission over distances up to 20 km, with signals transmitted in high quality. The unit is designed for indoor use and complies with IEEE 802.3 Ethernet and IEEE 802.3u Fast Ethernet standards, ensuring compatibility with common network environments.

Applications

The media converter is suitable for networks requiring extended reach beyond copper cables, for example in buildings, industrial facilities, or for connecting locations over long distances. It is frequently used in environments where high data integrity and reliability are required, such as office buildings, server rooms, or when connecting outdoor stations. The conversion from 10/100Base-TX to 100Base-FX enables the use of existing copper cabling on one end and fiber optic on the other, thereby optimizing infrastructure utilization.

Functions and Features in Detail

The converter features a Link Fault Pass Through function, which enables quick detection of network disruptions. In the event of a fiber optic connection failure, the error is passed on to the connected device, allowing the administrator to directly identify the cause. The unit is designed as a standalone device and is powered via an external power supply. The operation is intuitively designed, enabling quick installation and commissioning. The device is black in color and has a compact form factor with dimensions of 95 mm (length/depth), 70 mm (width), and 26 mm (height).

Technology Explained Simply

The converter operates with singlemode fiber optic and a wavelength of 1310 nm, ensuring high transmission reach and low signal loss. Data transmission occurs via a duplex system, using two fibers for bidirectional communication. The conversion takes place between the copper standard 10/100Base-TX and the fiber optic standard 100Base-FX, maintaining a speed of 100 Mbit/s on both sides. The use of SC connectors ensures a secure and standardized connection with fiber optic cables.

Compatibility and Accessories

The converter is compatible with networks supporting IEEE 802.3 and IEEE 802.3u standards. It can be used in existing Ethernet infrastructures to extend reach without replacing the entire copper cabling. Connection is made via an RJ45 connector on the copper side and an SC connector on the fiber optic side. The unit is designed for indoor use and requires no special accessories for installation.

Mounting and Installation

Mounting is done in a standard 19-inch rack or on a freestanding surface. The unit is compact and can be easily integrated into existing networks. Installation does not require special tools, as connections can be made directly. The quick start guide included in the delivery supports setup.

Operational Advantages

Operation of the converter is low-maintenance and reliable. The high reach of up to 20 km enables connection of locations far apart without requiring additional amplifiers. The Link Fault Pass Through function improves network monitoring by enabling rapid identification of faults. Compliance with Ethernet standards ensures seamless integration into existing networks. The combination of copper and fiber optic connections offers flexibility in network design and reduces costs associated with a full fiber optic conversion.

Delivery Contents

The delivery includes the DIGITUS Fast Ethernet media converter DN-82021-1, a quick start guide, and an external power supply. These components are sufficient to immediately put the converter into operation.

General
Product typeMedia converter
ManufacturerDIGITUS
Cable typeSingle mode
Wavelength1310 nm
Transmission range20 km
Ethernet standardIEEE 802.3, IEEE 802.3u
Copper connectionRJ45
Fibre optic connectionSC
Data rate100 Mbit/s
Operating voltageexternal power supply
Application rangeIndoor
ColourBlack
FunctionLink Fault Pass Through
Scope of deliveryMedia converter, quick start guide, power supply


Product data sheet
Datasheet for DIGITUS DN-82021-1, EAN: 4016032293101

Questions & answers

What is the delivery time of DIGITUS DN-82021-1 Media converter Fast Ethernet RJ45/SC Singlemode?

The article DIGITUS DN-82021-1 Media converter Fast Ethernet RJ45/SC Singlemode is currently in stock

According to our experience the article is ready for dispatch within 7 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of DIGITUS DN-82021-1 to our sales team for an exact delivery time.

How can I buy the item at a lower price?

We offer you DIGITUS DN-82021-1 Media converter Fast Ethernet RJ45/SC Singlemode always at the best possible price. We can give you a discount of 2% on DIGITUS DN-82021-1 Media converter Fast Ethernet RJ45/SC Singlemode if you choose payment in advance on ordering.

In addition, you can save money with our attractive graduated prizes with every purchase. If you buy a minimum of 10 pieces of DIGITUS DN-82021-1 Media converter Fast Ethernet RJ45/SC Singlemode we can offer you a price of 40,52 EUR per piece. The more you buy, the cheaper the article will be.

We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
