DIGITUS DN-19 FAN-4-B-N Roof fan unit Unique/Dynamic 4 fans black

Your rating:
Average rating
product review for DIGITUS DN-19 FAN-4-B-N Roof fan unit Unique/Dynamic 4 fans black
( 5 / 5 ) 1 ratings
DIGITUS DN-19 FAN-4-B-N
This image may differ from the desired article.
DIGITUS DN-19 FAN-4-B-NDIGITUS DN-19 FAN-4-B-N
264,76 EUR
( 315,06 EUR incl. VAT )
≈ £221.60  |  ≈ $290.97
plus delivery charges: 55,00 €
Delivery time from supplier's stock (ca.) 9 workdaysinfo_outline
In Stock: >10 pieces
1x DIGITUS DN-19 FAN-4-B-N Roof fan unit Unique/Dynamic 4 fans black
Lieske Part No.:185397
Mfg Part No: DN-19 FAN-4-B-N
UPC/EAN: 4016032332855
Weight:4.6 kg
Type:DN-19FAN-4-B-N
Graduated prices net
From piecesPrice per pieces
4252,85 EUR
8240,93 EUR
12229,02 EUR
16217,10 EUR

Product information for DIGITUS DN-19 FAN-4-B-N:

The DIGITUS roof fan unit DN-19FAN-4-B-N is a 19-inch accessory module for network enclosures, specifically developed for dissipating waste heat from IT components. The unit is finished in black (RAL 9005) and features four integrated fans that actively exhaust heat from the enclosure area upwards. It is designed for installation in the roof module of 483 mm (48,3 cm ( 19 inch )) network enclosures and is suitable for all models of the Unique and Unique Light series, as well as server enclosures of the Unique Server-N series. Additionally, it is compatible with network and server enclosures of the Dynamic Basic series, as well as unmounted 19-inch enclosures of the -EC series.

Applications

The roof fan unit is used for thermal dissipation of heat generated by IT components such as switches, routers, or servers within the enclosure. It is particularly useful in environments with high equipment density or limited air circulation, ensuring consistent cooling performance and extending the lifespan of the devices. The unit is intended for indoor use, as it has IP20 protection rating, which provides protection against solid foreign objects but not against water or dust.

Functions and Equipment in Detail

The fan unit is equipped with an adjustable thermostat that regulates temperature between 0 °C and +70 °C. This enables automatic adjustment of fan operation according to ambient temperature. Additionally, a manual ON/OFF switch is integrated, allowing direct control of the fans. Installation is performed via screw fastening in the roof module of the enclosure, and the mounting process is quick and simple.

Technology Explained Simply

The four fans provide an airflow of 9.2 cubic meters per minute, ensuring efficient cooling of devices installed in the enclosure. The noise level is 47 dBm, which is acceptable for a professional IT environment. Power supply is via a 1.8 m long power cord with a CEE 7/7 (Type-F) plug, which connects to a standard power socket. The unit is EMC-compliant, minimizing interference from electromagnetic fields.

Compatibility and Accessories

The roof fan unit is specifically developed for DIGITUS Compact and Unique enclosure series. It fits all network enclosures of the Unique and Unique Light series, as well as server enclosures of the Unique Server-N series. Additionally, it is compatible with network and server enclosures of the Dynamic Basic series and unmounted 483 mm (19 inch) enclosures of the -EC series. The delivery includes the roof fan unit and the required mounting hardware.

Installation and Mounting

Mounting is performed in the roof module of the enclosure using screw fastening. The unit is simply inserted into the designated module and secured with the included screws. Power supply is via the 1.8 m long power cord with CEE 7/7 plug, which connects to a suitable socket. Installation is possible without special tools or additional components.

Operational Advantages

The integrated temperature control via thermostat enables energy-efficient operation, as the fans are only activated when needed. The manual switch provides additional control, for example during maintenance or temporary shutdown. The robust construction and use of fans with high airflow ensure reliable cooling performance in IT infrastructures. The unit is designed for indoor use and meets EMC compliance requirements.

General
ColourBlack RAL 9005
Number of fans4
Thermostatadjustable from 0 °C to +70 °C
SwitchON/OFF switch
Supply cable1,8 m
Connector typeCEE 7/7 (Type-F)
Airflow9,2 m³/min
Noise level47 dBm
Degree of protectionIP20
Length/depth415 mm
CompatibilityUnique, Unique Light, Unique Server-N, Dynamic Basic, -EC series
EMCYes


Questions & answers

What is the delivery time of DIGITUS DN-19 FAN-4-B-N Roof fan unit Unique/Dynamic 4 fans black?

The article DIGITUS DN-19 FAN-4-B-N Roof fan unit Unique/Dynamic 4 fans black is currently in stock

According to our experience the article is ready for dispatch within 9 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of DIGITUS DN-19 FAN-4-B-N to our sales team for an exact delivery time.

How can I buy the item at a lower price?

We offer you DIGITUS DN-19 FAN-4-B-N Roof fan unit Unique/Dynamic 4 fans black always at the best possible price. We can give you a discount of 2% on DIGITUS DN-19 FAN-4-B-N Roof fan unit Unique/Dynamic 4 fans black if you choose payment in advance on ordering.

In addition, you can save money with our attractive graduated prizes with every purchase. If you buy a minimum of 4 pieces of DIGITUS DN-19 FAN-4-B-N Roof fan unit Unique/Dynamic 4 fans black we can offer you a price of 252,85 EUR per piece. The more you buy, the cheaper the article will be.

We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
