DEHN 405020 PAK20AQ495STTZN PA terminal for HVI cable St/tZn-NIRO D 20 mm

Your rating:
Average rating
product review for DEHN 405020 PAK20AQ495STTZN PA terminal for HVI cable St/tZn-NIRO D 20 mm
( 4.7 / 5 ) 16 ratings
DEHN 405020
This image may differ from the desired article.
DEHN 405020DEHN 405020DEHN 405020
9,50 EUR
( 11,31 EUR incl. VAT )
≈ £7.95  |  ≈ $10.44
plus delivery charges: 55,00 €
Made to order · Delivery time approx. 20 workdaysinfo_outline
1x DEHN 405020 PAK20AQ495STTZN PA terminal for HVI cable St/tZn-NIRO D 20 mm
Datasheet:file_download Download
Lieske Part No.:168055
Mfg Part No: 405020
UPC/EAN: 4013364098459
Weight:0.093 kg
Type:PAK 20 AQ4 95 STTZN
Graduated prices net
From piecesPrice per pieces
259,14 EUR
508,79 EUR
1008,43 EUR
2508,08 EUR

Product information for DEHN 405020:

The DEHN PA clamp type PAK 20 AQ4 95 STTZN is a specific earthing element for the secure connection of the special sheath of an HVI cable with the equipotential bonding system. It serves in the field of electrical installation as a fixed connection between the sheath of high-voltage interconnection cables (HVI) and the earthing system, to equalize electrical potentials and thus ensure operational safety. The clamp is designed for use in installations with increased requirements for earthing and equipotential bonding, particularly in industrial or technical installations where HVI cables are used.

Applications

The clamp is primarily used in the field of electrical installation, where HVI cables with a special sheath must be connected to ensure equipotential bonding. This includes particularly installations in the field of energy supply, industrial electrical installations, as well as buildings with special earthing requirements. The connection is made directly between the sheath of the HVI cable and the earthing system, ensuring a reliable electrical contact.

Functions and Equipment in Detail

The PA clamp enables a secure and durable connection of the special sheath of the HVI cable to the equipotential bonding system. It is designed for a diameter adjustment of 20 mm, enabling use with corresponding cable cross-sections. The clamp is made of steel with zinc-nickel coating (St/tZn-NIRO), ensuring high corrosion resistance and longevity under industrial conditions. The coating ensures a stable electrical contact and protects the clamp from environmental influences.

Technology Explained Simply

The clamp functions as a mechanical and electrical transition element. It is attached to the special sheath of the HVI cable and connected to the equipotential bonding system, creating an electrical contact that minimizes voltage differences between different parts of the installation. The use of steel with zinc-nickel coating ensures high electrical conductivity and mechanical strength. The coating prevents oxidation and corrosion, extending the clamp's service life and increasing the reliability of the earthing system.

The clamp is specifically designed for use with HVI cables that have a special sheath. The connection is made directly to this sheath, establishing a reliable contact with the equipotential bonding system. The clamp is not intended for other cable types or applications, but exclusively for connecting the special sheath of the HVI cable.

Compatibility and Accessories

The clamp is specifically designed for HVI cables with a special sheath. Compatibility is limited to use with these cables. The clamp is supplied as a single unit and is intended for direct mounting on the cable and the equipotential bonding system.

Installation and Mounting

Mounting is done by mechanical fastening to the special sheath of the HVI cable, followed by connection to the equipotential bonding system. The clamp is designed for a diameter adjustment of 20 mm, enabling use with corresponding cable cross-sections. Installation requires no additional tools or materials, except for the necessary tools for mechanical fastening. The clamp is directly attached to the cable and connected to the earthing system, creating an electrical contact.

Operational Advantages

The PA clamp ensures a reliable and durable electrical contact between the special sheath of the HVI cable and the equipotential bonding system. The use of steel with zinc-nickel coating ensures high corrosion resistance and longevity, increasing the reliability of the earthing system. The clamp is specifically designed for use in installations with increased earthing requirements and provides a secure connection that minimizes voltage differences and ensures operational safety.

General
ApplicationConnection of the special sheath of the HVI cable to the equipotential bonding
Diameter20 mm
Material of cage clampSt/tZn
Clamping range Ø20 mm
Connection cross-section4-95 mm²


Product data sheet
Datasheet for DEHN 405020, EAN: 4013364098459

Questions & answers

What is the delivery time of DEHN 405020 PAK20AQ495STTZN PA terminal for HVI cable St/tZn-NIRO D 20 mm?

The article DEHN 405020 PAK20AQ495STTZN PA terminal for HVI cable St/tZn-NIRO D 20 mm is currently not in stock and must be ordered on a per-order basis.

According to our experience the article is ready for dispatch within 20 working days. The delivery time usually refers to 1 piece. When ordering larger quantities, we can maybe shorten the delivery time. Just send us an inquiry about the desired quantity of DEHN 405020 to our sales team for an exact delivery time.

How can I buy the item at a lower price?

We offer you DEHN 405020 PAK20AQ495STTZN PA terminal for HVI cable St/tZn-NIRO D 20 mm always at the best possible price. We can give you a discount of 2% on DEHN 405020 PAK20AQ495STTZN PA terminal for HVI cable St/tZn-NIRO D 20 mm if you choose payment in advance on ordering.

In addition, you can save money with our attractive graduated prizes with every purchase. If you buy a minimum of 25 pieces of DEHN 405020 PAK20AQ495STTZN PA terminal for HVI cable St/tZn-NIRO D 20 mm we can offer you a price of 9,14 EUR per piece. The more you buy, the cheaper the article will be.

We also offer individual prices for your needs. You can get an offer by using the form Wholesale Inquiry.
