D-Link DNH-100 Nuclias Connect Hub content_copy

Nuclias Connect Hub, central management for 100 access points and license-free, cost-effective; no additional server required to manage access points, powerful management, monitoring and troubleshooting features, access via downloadable app or standard web browser, single sign-on (SSO) portal for centralized remote management of multiple Nuclias Connect Hubs , 1x 10/100/1000 MBit/s TP (RJ-45) LAN port, 1 x MicroSD slot, 1x USB 3.0 port, serial RJ-45 console port, supports AP grouping, multi-tenancy, visualized topology, NAT -Pass-Through, Setup Wizard, AP Discovery (Layer 2 and Layer 3), Reporting System, L2 Roaming, Band Steering, Airtime Fairness Captive Portal, Management via HTTP/Telnet, Compatible D-Link Access Points: DAP-2610, DAP- 2680, DAP-2682, DAP-3666, DAP-2662, DAP-2622, DAP-X2810, DAP-X2850, DIS-2650AP, DIS-3650AP, external power supply 12VDC/2.5A with EURO plug connection cable, table and Rack mounting (rubber feet and 19-inch installation material included)

Highlights

• Management of up to 100 DAP access points
• Integrated hotspot manager for voucher portal / guest WiFi
• Bandwidth management
• 8 SSIDs per band
• Integrated payment gateway function (Paypal)
• Rack mounting possible

Product type

• WLAN controller
• ear category (ElektroG): relevant, Category 6: small IT and telecommunications technology devices, small IT and telecommunications technology devices B2C

Shipping

• WEEE: 10490255

Data transmission

• Bandwidth: 10/100/1000 MBit/s

Basic features

• Color: White
• Height: 31 mm
• Length/Depth: 100 mm
• Width: 190 mm
• Weight: 529 g

Scope of delivery

• 1 x D-Link DNH -100 Nuclias Connect Hub

Design
Product colour	White
LED indicators	Power
Certification	FCC Class B, CE, C-Tick, VCCI, BSMI, cUL, CB, LVD (En60950-1)
Power LED
Management features
Web-based management
Rate limiting
VLAN support
Network
Ethernet LAN data rates	10,100,1000 Mbit/s
Networking standards	IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Ethernet LAN
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95%
Storage temperature (T-T)	-20 - 70 °C
Packaging content
Manual
User guide
Performance
Firewall throughput	100 Mbit/s
Number of LAN Access Points (max)	2
Ports & interfaces
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	1
Power
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	6.5 W
Power over Ethernet (PoE)
Security
Security algorithms	WPA2, WPA3
Weight & dimensions
Dimensions (WxDxH)	190 x 100 x 31 mm
Weight	529 g
Width	190 mm
Depth	100 mm
Height	31 mm

---
